Emerson LC320EM82 Service Manual

20071005 13-3 A71FFEL
FUNCTION CBA
R621 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R622 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R633 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R634 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R635 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R639 CHIP RES. 1/10W J 560 Ω RRXAJR5Z0561
R641 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R642 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R643 METAL OXIDE FILM RES. 2W J 0.12 Ω RN02R12DP004
R644 PCB JUMPER D0.6-P5.0 JW5.0T
R645 CARBON RES. 1/4W J 12k Ω RCX4JATZ0123
R646 CARBON RES. 1/4W J 15k Ω RCX4JATZ0153
R649 METAL OXIDE FILM RES. 1W 470 Ω RN01471DP003
R651 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R654 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R655 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R656 CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R657 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R658 CHIP RES. 1/10W F 620 Ω RRXAFR5H6200
R660 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R661 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R662 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R663 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R664 CHIP RES. 1/10W F 6.8k Ω RRXAFR5Z6801
R665 CHIP RES. 1/10W J 2.7k Ω RRXAJR5Z0272
R666 CHIP RES. 1/10W F 2.2k Ω RRXAFR5H2201
R667 CHIP RES. 1/10W F 82.0 k Ω RRXAFR5H8202
R671 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R672 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R673 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R676 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R677 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R678 CHIP RES. 1/10W J 6.8k Ω RRXAJR5Z0682
R682 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R683 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R684 CHIP RES. 1/10W J 56k Ω RRXAJR5Z0563
R691 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R692 CARBON RES. 1/4W J 33k Ω RCX4JATZ0333
R694 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R695 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R696 CHIP RES. 1/10W J 56k Ω RRXAJR5Z0563
R800 PCB JUMPER D0.6-P12.5 JW12.5T
R801 CHIP RES. 1/10W F 100k Ω RRXAFR5H1003
R802 CHIP RES. 1/10W J 390k Ω RRXAJR5Z0394
R803 CARBON RES. 1/4W J 22 Ω RCX4JATZ0220
R804 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R805 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R806 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R807 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R808 CHIP RES. 1/10W F 16.0 k Ω RRXAFR5H1602
R809 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R810 CHIP RES. 1/10W F 16.0 k Ω RRXAFR5H1602
R812 CHIP RES. 1/10W J 270k Ω RRXAJR5Z0274
R813 CHIP RES. 1/10W F 100k Ω RRXAFR5H1003
R814 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R815 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R816 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R817 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R819 CHIP RES. 1/10W J 2.7k Ω RRXAJR5Z0272
R820 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R855 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R859 CHIP RES. 1/10W J 10 Ω RRXAJR5Z0100
R860 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
Ref. No. Description Part No.
R863 CHIP RES. 1/10W J 3.6k Ω RRXAJR5Z0362
R864 CHIP RES. 1/10W J 3.6k Ω RRXAJR5Z0362
R865 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R866 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R869 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R870 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
B10 HEAT SINK PKH ASSEMBLY L3201UB 1EM420648
B11 HEAT SINK PKP ASSEMBLY L4200EA 1EM420855
BC601 PCB JUMPER D0.6-P5.0 JW5.0T
BC602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC632 PCB JUMPER D0.6-P5.0 JW5.0T
BC633 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC634 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC635 PCB JUMPER D0.6-P5.0 JW5.0T
BC1602 PCB JUMPER D0.6-P5.0 JW5.0T
FC601 CORE FERRITE TOROIDAL HF40T18X10X10 XL04018TE001
JS612 PCB JUMPER D0.6-P7.5 JW7.5T
JS632 PCB JUMPER D0.6-P15.0 JW15.0T
JS802 PCB JUMPER D0.6-P5.0 JW5.0T
JS803 PCB JUMPER D0.6-P5.0 JW5.0T
JS1601 PCB JUMPER D0.6-P12.5 JW12.5T
L6 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T601# TRANS POWER 7732 LTT2PC0KT027
Ref. No. Description Part No.
FUNCTION CBA(MPS-2)
Consists of the following:
----------
CAPACITORS
C108 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C110 ZENER DIODE EDZTE61 5.6B QD1B00EDZ5R6
CONNECTOR
CN102 CONNECTOR PRINT OSU S6B-PH-K-
S(LF)(SN)
J3PHC06JG030
RESISTORS
R118 PCB JUMPER D0.6-P5.0 JW5.0T
R119 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R120 CHIP RES. 1/10W F 6.8k Ω RRXAFR5H6801
R121 CHIP RES. 1/10W F 4.7k Ω RRXAFR5H4701
R122 CHIP RES. 1/10W F 2.7k Ω RRXAFR5H2701
R123 CHIP RES. 1/10W F 2.2k Ω RRXAFR5H2201
R124 CHIP RES. 1/10W F 1.5k Ω RRXAFR5H1501
R125 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R126 CHIP RES. 1/10W F 1.5k Ω RRXAFR5H1501
SWITCHES
SW108 TACT SWITCH SKQSAB SST0101AL038
SW109 TACT SWITCH SKQSAB SST0101AL038
SW110 TACT SWITCH SKQSAB SST0101AL038
SW111 TACT SWITCH SKQSAB SST0101AL038
SW112 TACT SWITCH SKQSAB SST0101AL038
SW113 TACT SWITCH SKQSAB SST0101AL038
SW114 TACT SWITCH SKQSAB SST0101AL038
MISCELLANEOUS
BC102 PCB JUMPER D0.6-P5.0 JW5.0T
JS101 PCB JUMPER D0.6-P5.0 JW5.0T
JS103 PCB JUMPER D0.6-P5.0 JW5.0T
Ref. No. Description Part No.
