Emerson LC320EM82 Service Manual

20071005 13-4 A71FFEL
IR SENSOR CBA
JACK CBA
Ref. No. Description Part No.
IR SENSOR CBA(MPS-3)
Consists of the following:
----------
CAPACITORS
C101 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C102 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C105 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C106 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C107 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
CONNECTOR
CN001 PH CONNECTOR SIDE 8P S8B-PH-K-
S(LF)(SN)
J3PHC08JG030
DIODES
D101 LED L-53HT NP4Z000L53HT
D102 LED 333GT/E NPHZ00333GTE
RESISTORS
R101 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R102 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R103 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R104 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R105 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
MISCELLANEOUS
BC101 PCB JUMPER D0.6-P5.0 JW5.0T
RCV891 PHOTO LINK MODULE KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
JACK CBA(MPS-4)
Consists of the following:
----------
CAPACITORS
C7001 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C7002 CHIP CERAMIC CAP.(2125) F Z 10µF/10V CHE1AZ30F106
C7003 CHIP CERAMIC CAP.(2125) F Z 10µF/10V CHE1AZ30F106
C7004 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7005 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7006 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7007 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7008 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7009 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7010 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7012 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7013 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7101 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C7102 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C7109 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7110 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7111 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C7602 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7605 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7608 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7611 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7615 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7618 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7621 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7624 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7701 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7702 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7705 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7706 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7709 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7710 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7714 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7715 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7718 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7719 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7723 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7724 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7729 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7730 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7733 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7734 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7738 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7739 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7743 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7744 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7747 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7748 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7751 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7752 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7801 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
C7802 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
CONNECTOR
CN7501 FMN CONNECTOR TOP 24P 24FMN-BTK-
A(LF)(SN)
JCFNG24JG019
IC
IC7001 IC VIDEO ANALOG INTERFACE R2A11011FP
QFP 56PIN
QSZBA0RHT066
COILS
L7802 PCB JUMPER D0.6-P5.0 JW5.0T
L7803 PCB JUMPER D0.6-P5.0 JW5.0T
RESISTORS
R7001 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7002 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7101 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7102 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7103 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7104 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7105 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R7106 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R7111 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7112 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7502 PCB JUMPER D0.6-P5.0 JW5.0T
R7503 PCB JUMPER D0.6-P5.0 JW5.0T
R7504 PCB JUMPER D0.6-P5.0 JW5.0T
R7601 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7602 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7604 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7605 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7607 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7608 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7610 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7611 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7613 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7614 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7616 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7617 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7619 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7620 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7622 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7623 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7701 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7702 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7708 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7709 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7715 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
Ref. No. Description Part No.
