Emerson LC320EM82 Service Manual

20071005 13-8 A71FFEL
R1116 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1117 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1118 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1119 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1120 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1121 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1160 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1161 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1162 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1163 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1164 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1165 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1166 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1167 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1168 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1169 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1170 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1171 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1210 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1211 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1212 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1213 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1214 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1215 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1216 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1217 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1218 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1219 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1220 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1221 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1250 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1251 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1252 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1253 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R1254 PCB JUMPER D0.6-P5.0 JW5.0T
R1255 PCB JUMPER D0.6-P5.0 JW5.0T
R1260 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1261 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1262 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1263 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1264 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1265 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1266 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1267 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1268 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1269 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1270 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1271 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1310 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1311 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1312 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1313 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1314 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1315 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1316 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1317 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1318 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1319 CHIP RES. 1/10W F 8.2k Ω RRXAFR5H8201
R1320 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1321 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1500 CHIP RES. 1/10W F 47.0 k Ω RRXAFR5H4702
R1501 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R1504 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
Ref. No. Description Part No.
R1505 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1506 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1507 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1508 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1509 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1510 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1511 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1550 CHIP RES. 1/10W F 47.0 k Ω RRXAFR5H4702
R1551 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R1554 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1555 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1556 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1557 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1558 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1559 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1560 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1561 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1701 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1702 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R1703 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
MISCELLANEOUS
AC501# AC CORD W/O A GND WIRE UL 1935MM
BLACK
WAC0192LW003
B12 HEAT SINK PMI ASSEMBLY A71F0UH 1EM424257
BC501 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC502 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC552 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC553 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1000 PCB JUMPER D0.6-P5.0 JW5.0T
BC1001 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1050 PCB JUMPER D0.6-P12.5 JW12.5T
BC1051 PCB JUMPER D0.6-P12.5 JW12.5T
BC1100 PCB JUMPER D0.6-P10.0 JW10.0T
BC1101 PCB JUMPER D0.6-P10.0 JW10.0T
BC1150 PCB JUMPER D0.6-P12.5 JW12.5T
BC1151 PCB JUMPER D0.6-P12.5 JW12.5T
BC1200 PCB JUMPER D0.6-P10.0 JW10.0T
BC1201 PCB JUMPER D0.6-P10.0 JW10.0T
BC1250 PCB JUMPER D0.6-P10.0 JW10.0T
BC1251 PCB JUMPER D0.6-P10.0 JW10.0T
BC1300 PCB JUMPER D0.6-P10.0 JW10.0T
BC1301 PCB JUMPER D0.6-P10.0 JW10.0T
CLN552 WIRE ASSEMBLY 001 8PIN / 190MM / AWG26 WX1A71F0-001
F501# FUSE STC4A125V U/CT PAGE20CW3402
FC501 CORE FERRITE TOROIDAL HF40T18X10X10 XL04018TE001
FH501 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH502 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
GP501# GAP. FNR-G3.10D FAZ000LD6005
JS553 PCB JUMPER D0.6-P5.0 JW5.0T
JW501 PCB JUMPER D0.6-P15.0 JW15.0T
L6 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA502# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
T501# TRANS POWER 7715 LTT3PC0KT024
T1050 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1100 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1150 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1200 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1250 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1300 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
Ref. No. Description Part No.
