20071005 13-9 A71FFEL
JUNCTION CBA
DIGITAL SUB CBA
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTOR
CN552 242 SERIES CONNECTOR TUC-P08X-B1 WHT
ST
JCTUB08TG002
Ref. No. Description Part No.
DIGITAL SUB CBA
Consists of the following:
1ESA15014
CONNECTOR
CN1 ANGLE PIN HEADER IMSA6029B105Z003PT1 JTED005ER045
TRANSISTORS
Q1 PNP TRANSISTOR POWER 2SA1887(F) QQWZ2SA1887F
Q2 PNP TRANSISTOR POWER 2SA1887(F) QQWZ2SA1887F
Q3 PNP TRANSISTOR POWER 2SA1887(F) QQWZ2SA1887F
RESISTORS
R1 METAL OXIDE FILM RES. 2W J 0.68 Ω RN02R68DP004
R3 METAL OXIDE FILM RES. 2W J 0.68 Ω RN02R68DP004
R4 METAL OXIDE FILM RES. 2W J 0.68 Ω RN02R68DP004
R5 METAL OXIDE FILM RES. 2W J 0.68 Ω RN02R68DP004
