Stand Assembly
Attaching the Base
You must attach the base to the Unit to have it as a table top Unit.
Be sure the front and rear of the base match the proper direction. For
large screen TVs, at least 2 people are required for these steps.
1
2
Note(s)
●
Make
sure to use a table which can support the weight of this Unit and is larger than this
Unit.
●
Make sure the table is in a stable location.
●
When attaching the base, ensure that “FRONT” with “arrow” written on the bottom of
the base is downward. If it’s not downward, the 2 hooks don’t fit into the base.
●
When attaching the base, ensure that All Screws are tightly fastened. If the base is not
properly attached, it could cause the Unit to fall, resulting in injuries as well as damage to
the Unit.
●
To remove the base from this Unit, unscrew the Phillips head screws in step 2. Be careful
not to drop the base when you remove it.
Installing the Remote Control Batteries
1
Slide the battery cover off the back of the Remote Control.
2
Insert 2 Batteries (AAA, 1.5V). Be sure the + and – ends of the
Batteries line up with the markings inside the case.
3
Slide the cover back into position.
Note(s)
●
Remove the Batteries if not using the Remote Control for an extended period of time.
8 .English
Continued on next page.
