Emerson Rosemount 304 - Selection guide; Rosemount 305 Integral Manifold; Rosemount 306 In-line Manifold; Rosemount 304 Conventional Manifold

2
Rosemount Manifolds
August 2016
EmersonProcess.com/Rosemount
Selection guide
Rosemount 305 Integral Manifold
See “Rosemount mounting brackets” on page 27.
 Assembles directly to transmitter, eliminating need for flange
 2-, 3-, and 5-valve configuration
 Available with vertical or horizontal process connections
 Compact, lightweight assembly
 Factory assembled, seal-tested, and calibrated
 50% fewer leak points than conventional transmitter to flange to
manifold interface
 Female NPT process connections
Rosemount 306 In-line Manifold
See “Rosemount mounting brackets” on page 27.
 Assembled directly to in-line pressure transmitters
 Block-and-bleed and 2-valve configurations
 Male or female threaded NPT process connection
Rosemount 306 In-line Manifold
Rosemount 304 Conventional Manifold
See “Rosemount mounting brackets” on page 27.
 Attaches to transmitter flange
 2-, 3-, and 5-valve configurations
 Traditional (Flange ⫻ Flange, Flange ⫻ NPT) and wafer styles
 Factory assembled, seal-tested, and calibrated
Rosemount 304 Conventional Manifold - Traditional Style
Rosemount 304 Conventional Manifold - Wafer Style
Contents
Valve configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Rosemount 305 Integral Manifold -
Coplanar Style
Rosemount 305 Integral Manifold -
Traditional Style
