Rosemount Manifolds
August 2016
EmersonProcess.com/Rosemount
Specification and selection of product materials, options, or components must be made by the purchaser of the equipment. See page 12
for more information on material selection.
Table 2. Rosemount 305 Integral Manifold Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
The Expanded offering is subject to additional delivery lead time.
Model Product description
0305 Integral manifold
Manufacturer
R Rosemount ★
Manifold style
C Coplanar ★
T Traditional ★
M Traditional (DIN-compliant flange) ★
Manifold type
2 2-valve ★
3 3-valve ★
5
(1)
5-valve ★
6
(2)
5-valve natural gas metering pattern ★
7
(2)(3)
2-valve (per ASME B31.1 [ANSI] power and piping code)
8
(2)(3)
3-valve (per ASME B31.1 [ANSI] power and piping code)
9
(2)(3)
5-valve (per ASME B31.1 [ANSI] power and piping code)
Body Bonnet Stem and tip/ball
2 316 SST/316L SST 316 SST 316 SST ★
3
(4)
Alloy C-276 Alloy C-276 Alloy C-276
4 Alloy 400 Alloy 400 Alloy 400/K-500
Process connection style
A
(5)
1
/4–18 NPT female ★
B
(6)
1
/2–14 NPT female ★
Packing material
1
(7)
PTFE ★
2
(8)
Graphite-based
Valve seat
1 Integral ★
5 Soft POM (only available with natural gas metering pattern) ★
Options
Extended product warranty
WR3 3-year limited warranty ★
WR5 5-year limited warranty
★
