Rosemount Manifolds
August 2016
EmersonProcess.com/Rosemount
Specification and selection of product materials, options, or components must be made by the purchaser of the equipment. See page 12
for more information on material selection.
Table 3. Rosemount 306 Pressure Manifold Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
The Expanded offering is subject to additional delivery lead time.
Model Product description
0306 Pressure manifold
Manufacturer
R Rosemount ★
Manifold style
T Threaded ★
Manifold type
1 Block-and-bleed ★
2 2-valve ★
3
(1)
2-valve (per ASME B31.1 power piping code)
Body Bonnet Stem and tip/ball
2 316 SST/316L SST 316 SST 316 SST ★
3
(2)(3)
Alloy C-276 Alloy C-276 Alloy C-276
Process connection
AA
1
/2–14 male NPT process connection for in-line transmitter ★
AW
1
/2–14 male NPT process connection for Rosemount Wireless Pressure Gauge ★
BA
(2)
1
/2–14 female NPT process connection for in-line transmitter ★
BW
1
/2–14 female NPT process connection for Rosemount Wireless Pressure Gauge ★
Packing material
1
(4)
PTFE ★
2
(5)
Graphite-based
Valve seat
1 Integral ★
Options
Extended product warranty
WR3 3-year limited warranty ★
WR5 5-year limited warranty
★
Cleaning
(6)
P2 Cleaning for special services
To Next Page
