Rev. 3 02-2021
14
DXi.H/DXi.HF - V
DXi.H/DXi.HF - D
DXi.H/DXi.HF - U
DXi.H/DXi.HF - B
MTEC.DXi.H/DXi.HF.GB-3 Use and Maintenance technical manual DXi.H/DXi.HF English
Emibyte DXi.H/DXi.HF Direct expansion close control
&RQÀJXUDWLRQV
Front suction
Up discharge
Down suction
Up discharge
Up suction
Down discharge
Discharge
Suction
Suction
Suction
Discharge
Discharge
Behind suction
Up discharge
Discharge
Suction
