EMM Labs NS1 - Features and Specifications

007
Features & Specifications
Features & Specications
File Streaming and Playback:
• from PCM (44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz)
• MQA® Core decoding up to 24bit, 96kHz*
• Single rate DSD (via DoP)
• AAC, AIFF, ALAC, FLAC, MP3, WAV and WMA le playback
Inputs:
• Network (RJ45)
• 2x USB type A (for USB storage and WiFi)
Digital Outputs:
• EMM Optilink
• AES/EBU
• TOSLINK SPDIF
Serial RS-232 port for Data Communication to EMM D/A Converters
Power supply:
• Power factor corrected
• Universal 100V to 240V, 50/60Hz operation
• Power consumption: 10W
• Dimensions W x D x H: 280 x 268 x 60mm
• Weight: 5kg
*When playing MQA® through the NS1 coupled with MQA®-enabled DAC, the NS1 will output MQA® Core decoded
signal. e MQA®-enabled DAC will display the original sample rate of the MQA® stream. In case of the DV2 DAC,
the Optilink input currently cannot fully render MQA® streams beyond the Core decoding of 24bit, 96kHz.
© EMM Labs Inc., All Rights Reserved. EMM Labs reserves the right to amend specifications & design without notice.
NS1 STREAMER QUICKSTART & OWNERS MANUAL
