Delivery Check
1 pc Folded chassis
1 pc Tray/Basket
2 pc Swivel wheels
2 pc Wheels
1 pc Instruction manual
1. Check that the following items are present in the correct numbers:
Chassis
2. Check the functions of the chassis/seat unit/carrycot:
Check that the chassis locks on both sides.
Check that the safety catch/safety buttons function correctly by folding the pram and checking
that the safety catch/safety buttons are activated to prevent accidental folding.
Check that the seat unit/carrycot clicks securely on to the chassis and that it locks on both sides.
Check the harness function on the seat unit by locking and unlocking the harness.
Check the handle height adjustment function by adjusting the handle up and down. The handle
should lock securely into each position.
Check that the Emmaljunga Adjustable Comfort System - adjustable suspension function can be
secured into the three positions on both sides of the chassis.
Check that the back rest can be adjusted and locked into each position.
Check that the footrest on the seat unit can be adjusted and locked into each position.
3. Wheels and brakes:
Lubricate the ends of the axles.
Attach the wheels and make sure that the wheels lock into position.
Check that the parking device locks both rear wheels when engaged.
4. Overall inspection of the product:
Check that all rivets, screws and nuts are securely fastened.
Check that all press studs and zips on the seat fabrics and the tray/basket
are correctly and securely attached.
Make sure that there are no other visible differences on the chassis, seat
fabrics, tray/basket and wheels.
Carrycot
Seat unit Ergo
Seat unit Flat
1 pc Carrycot
1 pc Apron for carrycot
1 pc Mattress
1 pc Seat unit Ergo with seat unit fabrics
incl 5-point harness
1 pc Hood
1 pc Bumper Bar
1 pc Seat unit Flat with seat unit fabrics incl
5-point harness
1 pc Hood
1 pc Bumper Bar
Chassis/seat unit/carrycot function
- Check that the chassis locks on both sides.
- Check that the safety catch/safety buttons function
correctly by folding the pram and checking that the
safety catch/safety buttons are activated to prevent
accidental folding.
- Check that the seat unit/carrycot clicks securely on
to the chassis and that it locks on both sides.
- Check the harness function on the seat unit by
locking and unlocking the harness.
- Check the handle height adjustment function by
adjusting the handle up and down. The handle
should lock securely into each position.
- Check that the Emmaljunga Adjustable Comfort
System - adjustable suspension function can be
secured into the three positions on both sides of
the chassis.
- Check that the back rest can be adjusted and
locked into each position.
- Check that the footrest on the seat unit can be
adjusted and locked into each position.
Wheels and brakes
Attach the wheels and make sure that the wheels lock
into position.
Check that the parking device locks both rear wheels
when engaged.
Visual overview
Check that all rivets, screws and nuts are securely
fastened.
Check that all press studs and zips on the seat
fabrics and the tray/basket are correctly and securely
attached.
Check for any other visible deviations on the chassis,
fabrics, tray/basket and wheels
Lubrication
Clean and lubricate the wheels, axles, chassis locks,
footrest and the safety catch
Other notes (further adjustments or changed details)
Service Protocol
Service 6 mo 12 mo 24 mo 36 mo
