EmmeGas READY - Standard A.E.B. Sensors

1234
0
1/2
4/4
ABCD
1 2 1 2 1 2 1 2
-
-
-
-
12 12 12 12
12
RPM
+
G
R
WHITE
GREEN
WHITE
GREEN
GROUND
GROUND
WHITE
GREEN
WHITE
GROUND
A.E.B. STANDARD SENSORS
A.E.B. STANDARD SENSORS
TYPE 1050
0÷90 OHM STANDARD
SENSORS
GREEN DO NOT CONNECT
GREEN/BLACK
GREEN
YELLOW/BLACK
YELLOW
GREY
VIOLET
PRESSURE REGULATOR
SOLENOID VALVE
BLUE
BLUE/BLACK
RED/BLACK
RED
BLUE
BLACK
RED/BLACK
BLACK
GROUND
CHANGE OVER
SWITCH
BLACK
ORANGE
ATTENTION
THE CONNECTOR OF THE GAS INJECTOR
A MUST
CORRESPOND TO THE
BLUE WIRE OF THE
CUT-INJECTOR CABLE
DIAGNOSTIC SOCKET
TO THE WATER
TEMPERATURE SENSOR
OXYGEN
SENSOR
BROWN
OPTIONAL
RED/WHITE
+12VOLT WITH IGNITION KEY
A.E.B.
GAS PRESSURE, TEMPERATURE
AND MAP SENSOR
WHITE/BLUE
FUEL TANK
SOLENOID VALVE
BLACK
+
-
MAX 15A
