Rear Panel & Functions
DAC2X AUDIO CONVERTER OWNER’S MANUAL
Rear Panel & Functions
5. Digital Inputs (All PCM inputs supporting up to 24bit, 192kHz):
• EMM Optilink: input for interconnection with an EMM Labs transport.
• AES/EBU: AES/EBU (XLR) PCM digital audio input.
• COAX: SPDIF (RCA) format PCM digital audio input.
• TOS1: SPDIF (TOSLINK) format PCM digital audio input.
• TOS2: SPDIF (TOSLINK) format PCM digital audio input.
• USB Audio: USB PCM and DSD audio from a computer, media player, server
• PDAI: SPDIF (RCA) format PCM digital audio input.
6. Analog Line Output:
• Le and Right Balanced (XLR) Connectors
• Le and Right Un-Balanced (RCA) Connectors
• Output Line Level with 0dBfs signal on AES/EBU input:
XLR outputs: 4.6Vrms (+15.45dBu)
RCA outputs: 2.3Vrms (+9.45dBu)
7. System
Remote:
• Wired RS232: RS232 communication port. See Appendix A.
Service:
• USB data port for rmware upgrades (see separate USB update
instructions)
• RESET button used to temporarily access the backup rmware.
Only for diagnostic purposes. Should not be used during normal
operation.
