Emos 15GD/3A - GB Mechanical Timer; Specification; Setting the Time; Setting of the Required Programme

4
GB
Mechanical Timer
Mini Mechanical Timer serves to switch power supply 230 V~ in the required time. Minimal setting
time is 30 minutes.
Specication
Power Supply: 230 V~, 50 Hz
Max. load: 16 (2) A 3 680 W
Temperature of environment: -10°C to +50°C
Total accuracy of timer: ±5 min
Accuracy on switch 30 min: ±5 s
Accuracy on switch 1 hour: ±10 s
Accuracy on switch 6 hours: ±1 min
IP20
Setting the Time
Turn the dial clockwise (as per indicating arrows) until the arrow located at the top right of the centre
dial, is pointing to the correct time. Make sure that the manual override switch on the top of the unit is
set the position. Each segment represents 30 minutes: 2 segments = 1 hour.
Setting of the Required Programme
1. Pull up all the segments on the edge of the rotating disc. One pulled up segment cuts o the timer
for 30 minutes (2 segments = 1 hour etc).
2. Turn the switch on the side of the timer into the down position . The switch works according to
the programme.
3. Plug the timer into the supply network 230 V~/50 Hz
4. Insert the appliance plug into the Timer plug.
Upper position I – socket is still switched on irrespective of the programme.
Down position – timer works according to the programme.
Warning
• Maximum induction load is 2 A.
• It is prohibited to open the product.
• Use the timer in dry indoor areas only.
• This appliance is not to be used by persons (including children), whose physical, sensible of mental
inability or the lack of experience or knowledge prevents them from safe usage of this appliance
unless they are supervised or have been instructed on safe usage by a person responsible for their
safety. Children should be supervised to be prevented from playing with the appliance.
Do not dispose with domestic waste. Use special collection points for sorted waste. Contact local
authorities for information about collection points. If the electronic devices would be disposed
on land ll, dangerous substanoes may reach groundwater and subsequently food chain, where
it could aect human health.
