GB | Thermostat
The P5606OT thermostat is designed for controlling heating and air-con-
ditioning systems.
Important
• Before the rst use, make sure to carefully read the operating
manual for the thermostat, as well as the manual for the boiler or
air-conditioning equipment.
• Turn o power supply before installing the thermostat!
• Installation should be carried out by qualied personnel!
• During installation, observe the prescribed standards.
Technical specications
Switched load: max. 230 V AC; 6 A for resistive load;
2 A for inductive load
Temperature measurement: 0 °C to 40 °C with 0.1 °C resolution
accuracy ±1 °C at 20 °C
Temperature setting: 5 °C to 35 °C in 0.5 °C increments
Dierential setting: 0.2 °C to 2 °C, in 0.1 °C increments
Power supply: 2× 1.5 V type AA (LR6) batteries
Back-up power supply: 1× 3 V type CR2032 battery
Accessories: 2 screws, 2 wall plugs
Dimensions and weight: 126 × 84 × 25.5 mm; 164 g
Description of Control Elements (See Fig. 1)
1 – Home (return to home screen)
2 – Next (move to the next option within the current function)
3 – Adjust value setting
4 – Conrm (conrm function selection)
5 – Copy
6 – Holiday mode
7 – Battery compartment
8 – Time and date setting
9 – Select and edit programme (PROG)
10 – Anti-freeze mode (OFF)
11 – Manual mode (MAN)
12 – Automatic mode (AUTO)
Display Description (See Fig. 2)
13 – Days
14 – Time
15 – Room temperature
16 – Heating
/ cooling
17 – Set temperature
