4
GB | Thermostatic and Timer Socket
This digital socket combines a switch socket for timed activation/
deactivation of home appliances with a thermostatic socket for auto-
matic regulation of electrical heating and cooling systems (convector
heaters, ladder radiators, infrared heating panels, air-conditioning).
Technical Specications
Power supply: 230 V~, 50 Hz, 16 A max.
IP rating: IP30
Operating temperature: 0 °C to 55 °C
increment for setting time: 1 minute
Switched load: max. 230 V AC, 3,680 W; 16 A for resistive load;
4 A for inductive load
Temperature measurement: 0 °C to 45 °C with 0.1 °C resolution;
accuracy ±1 °C at 20 °C
Temperature setting: 5 °C to 40 °C in 0.5 °C increments
Temperature dierential setting: 0.2 °C to 2 °C,
in 0.1 °C increments
Back-up power supply: 1× 3 V CR2032 battery (included)
Dimensions: 82 × 62 × 146 mm
Description of Control Elements (See Fig. 1)
1 – socket for connecting an
appliance
2 – BOOST button
3 – „−“ button
4 – TIME button
5 – screen
6 – temperature sensor
7 – PROG button
8 – „+“ button
9 – RESET
10 – MODE button
On-Screen Indicators in Thermostatic Mode (See Fig. 2)
1 – time mode
2 – programme number
3 – mode icon
4 – day number
5 – room temperature
6 – time/set temperature
7 – back-up battery low
On-Screen Indicators in Timer Mode (See Fig. 3)
1 – time mode
2 – mode icon
3 – day number
4 – time
5 – programme number
6 – back-up battery low
Back-Up Battery Replacement
The back-up battery is used to power the socket‘s memory.
The expected battery life is 2 years.
When
appears on the screen, replace the battery.
1. Remove the 4 screws on the back and take o the front cover
(see g. 4).
2. Remove the drained battery and insert a new one.
3. Make sure you observe the correct polarity: + side up.
4. Replace the cover and screw it back on.
A) USE IN THERMO-SWITCH SOCKET (THERMOSTAT) MODE
Socket Placement
Choose a spot preferably on an inside wall where air circulates freely
and there is no direct sunlight.
