GB | Surface Mount Thermostat
Properties
surface mount thermostat with display, designed for mounting onto pipes;
simple mounting using a tension spring;
5 °C – 80 °C temperature range (0.1 °C resolution);
simple electrical connection using screwless terminals.
Specications
Switched load: max. 230 V AC; 5 A for resistive load; 1.5 A for inductive load
Power supply: 230 V AC
Temperature control range: 5 °C– 80 °C
Temperature measurement: 5 °C to 80 °C with 0.1 °C resolution accuracy ±1.5 °C
Temperature setting: 5 °C to 80 °C in 0.1 °C increments
Hysteresis setting: 0.1 to 15 °C with 0.1 °C resolution
Enclosure: IP40
Thermostat Description
(see Fig. 1)
1 – activation indicator LED
2 – display
3 – up arrow (increase value)
4 – down arrow (decrease value)
5 – on/o/function setting button
6 – screws
7 – temperature sensor
Installation
1. Place the thermostat rmly onto a heater pipe and secure it with the enclosed tension spring so that
the thermostat (temperature sensor) is in direct contact with the pipe. (Any insulation on the insta-
llation spot must be removed before mounting the sensor. To achieve a more accurate temperature
measurement, it is recommended to use a heat conductive paste and clean the contact surface of dirt.)
2. Any excess spring can be cut o.
Electrical Connection
1. Remove the 2 screws on the front housing of the thermostat.
2. Carefully remove the front housing.
3. Connect in accordance with the following diagram (see Fig. 2):
Pump
Power – 230 V
Jump – jumper
PE – protective earth, prevents injury by electrical current
4. The thermostat features a screwless conductor connection. Press downwards onto the top plastic
connector with e.g. a screwdriver. The terminal contact will release. Plug in the conductor. Repeat
the process for all conductors needed for connection. Replace the screws.
The device may only be installed by a professional plumber in accordance with the connection
diagram. In addition, the connection must meet up-to-date, valid VDE standards and specications
of your energy provider. Installation must always be performed when power is turned o; follow
safety specications. Maintain the maximum switched load listed in technical specications! The
manufacturer is not liable for inexpert installation.
Putting the Device into Operation
Connect the thermostat with pump according to instructions.
Connect the thermostat to 230 V power supply.
Short-press the
button.
The currently set mode and heating/cooling mode setting will ash on the display (e.g.: F1/C1).
Then, the current temperature will be displayed.
