2.3.3 Mounting schemes
Fig. 15
FDU48: Model 300 to 500 (G and H)
FDU69: Model 250 to 400 (H69)
FDU48: Model 860 to 1K 0(J)
FDU69: Model 650 to 800 (J69)
FDU48: Model 600 to 750 (I)
FDU69: Model 430 to 595 (I69)
FDU48: Model 1K15 to 1K25 (KA)
FDU69: Model 905 to 995 (KA69)
