Empisal EIP003 - Parts List

11
PARTS LIST
Part#
Description
Qty.
Part#
Description
Qty.
1
PRESSURE IRON BOARD
1
42
LATCH AXLESNAP SPRING
2
2
ALUMINUM GUTTERED SHEET
2
43
CUICUIT BOARD ISOLATE WASHER
1
3
HEAT PLATE
2
44
CIRCUIT BOARD
1
4
COPPER NOZZLEFOR HEAT PLATE
2
45
HANDLE SPRING
1
5
TEMPERATURE CONTROL SWITCH
1
46
HANDLE SPRING GASKET(1)
1
6
PROBE FIX SHEET
1
47
HANDLE SPRING GASKET(2)
1
7
HIGH TEMPERATUREPLAIN WASHER FOR TEMPERATURE
CONTROL
1
48
HANDLE CONNECTING AXLE
2
8
IRON BOARD CONNECTING SHEET
1
49
MACHINE CONNECTING AXLE
1
9
CONNECTING SHEET SET BOLT
2
50
M5X20 COUNTERSUNK HEAD
2
10
IRON BOARD SET HOOKS(LONG)
3
51
DOUBLE-ROUND HEAD SILICON WASHER
1
11
IRON BOARD SET HOOKS(SHORT)
4
52
SLIDE LOCALIZATION PLASTICK BLOCK
2
12
M3X12STAINLESS STEEL SCREW ROUND HEAD
3
53
STAINLESS STEEL TRACK
2
13
HEAT SHIELD
1
54
RUBBER ANTICORROSION
2
14
INLET SILICON-RUBBER HOSE(THIN)
2
55
Z608 AXLETREE
2
15
INLET TEE
1
56
AXLETREE CONNECTING AXLE
1
16
SILICON TUBE SLEEVE
2
57
MACHING CONNECTING AXLETREE
2
17
TWISTTIE
1
58
PRESSING BOARD
1
18
PLASTIC BASE PLATE
1
59
DISPLAY MODULE
1
19
WATER PUMP
1
60
BUTTON
1
20
PLASTIC WATER TANK
1
61
PLASTIC SHIELD
1
21
WATER TANK COVER
1
61-1
FRONT COVER
1
22
INLET SILICON-RUBBER HOSE(THICK)
1
62
SHIELD COVER PLATE
1
24
M4X12STAINLESS STEEL SCREW COUNTERSUNK HEAD
2
63
PLASTIC LOCKING KNOB
1
25
M4X12STAINLESS STEEL SCREW ROUND HEAD
2
64
LOCKING KNOB SWITCH
1
26
BASE PLATE PLASTIC SCREW
1
65
SHIELD COVER PLATIC BOLT
2
27
BACK LEC
4
66
POWER SWITCH
1
28
M4X30 STAINLESS STEEL SCREW COUNTER SUNK
HEAD
2
67
STRAIN RECIEF BUSHING
1
29
PLASTIC ISOLATE PLATE
1
68
SECURING SCREW ANTISKID MAT
4
30
ALUMINUM ALLOY LOWER SHELL
1
69
PRESSING BOARD CONNECTING COPPER
WASHER
1
31
ALUMINUM ALLOY UPPER SHELL
1
70
CONNECTING SHEET SET SCREW SPRING
2
33
M3X12SELF TAPPING SCREW
2
71
LOCKNUT
2
34
CORD BOX PLASTIC SHEET
2
/001
IRON BOARD SHIELD COVER
1
35
PLASTICHANDLE
1
/003
∮6FLAT WASHER
1
36
STEAM BURST BOTTOM
2
/004
M5X20XOUNTERSUNK HEAD
4
37
STEAM BURST BOTTOM SILICON SLEEVE
2
/005
M6 NUT
4
38
M3X5 STAINESS STEEL SELF TAPPING COUNTER SUNK
HEAD
8
/006
SPLIT PINS
2
39
HEX SOCKET CAP SET SCREW
1
/007
LATERAL PINLOCK SCREW
2
40
LATCH AXLE
2
/008
PCB LOCK SCREW
2
41
LATCH AXLESPRING
2
/009
HEAT PLATE LOCK SCREW
10
