Safety information (continued)
Do not position the Emporia Vue so that it is difficult to
operate disconnecting devices or breakers.
Do not use 3rd party accessories or Current
Transformers (CTs) with the Emporia Vue. The Vue and
CTs are customized and integrated. Third party
accessories or CTs may compromise the data
accuracy and equipment safety.
The current transformers may not be installed in
equipment where they exceed 75 percent of the wiring
space of any cross-sectional area within the
equipment.
Restrict installation of current transformers in an area
where it would block ventilation openings.
Restrict installation of current transformers in an area
of breaker arc venting. Do not install the Emporia Vue
Energy Monitor in any area where breaker arc venting
exhaust gasses could be re-directed as a result of
submetering equipment installation.
The Emporia Vue is not suitable for Class 2 wiring
methods and not intended for connection to Class 2
equipment. (Refer to NEC 2023, Section 725.)
Secure current transformers and route conductors so
that the conductors do not directly contact live
terminals or buses.
The Emporia Vue shall not be mounted within 50.8 mm
(2 in) of any live parts including primary conductors,
primary terminals, and primary lugs; but excluding
insulated cables. It's acceptable for the Vue to be
mounted to the grounded panel box and near the
neutral/ground bus bars. The Vue employs Class I
wiring allowing its wires to safely coexist with all other
wires in the panel.
If the Emporia Vue Energy Monitor is attached to the
enclosure, it shall not contact the panel interior
insulation such as the material that separates the GND
and LIVE bus bars.
Emporia Vue Energy Monitor mounting provisions shall
not be attached to any energized part.
Voltage sensing and power supply connections to the
primary voltage shall have overcurrent protection
through connection to a breaker/MCB.
