CR-2000 Instructions Revision 1.0 02/20/2013
The CR-2000 is an inductive contact-less card reader in a metal water proof
housing that also acts as a keypad control. The CR-2000 provides safe secure
access control for any combination of 2000 users by the use of the Mifare pass
card or individual user pass codes.
The CR-2000 has low power consumption (30mA standby) luminous keypad
for nighttime use, Short circuit protection, tamper alarm output, and the
Wiegand output for monitoring of user access.
The CR-2000 may also be used stand alone for access control of doors, gate
and barrier arms.
• Low 30 mA standby current
• Luminous keypad: for nighttime operation
• 2000 user support
• Independent password support (may use code or card for access)
• Keypad user delete (for lost or stolen cards or codes)
• Output short circuit protection
• Wiegand output: Wg26 for cards or Wg4 for keypad
• Tamper alarm output
• Doorbell button: Independent from circuit works with any doorbell
• User pass card code change (allows user to use code they can
remember in case card is lost or forgotten)
Product Overview
Features
Technical Specifications
Operating Voltage 9-28 VDC
Current draw standby < / = 30 mA
Read range 1.1 in (3cm) – 3.1in (8cm)
Capacity (users) 2000 card and or pass codes
Operating Temperature -13
o
F (-25
o
C) to 140
o
F (60
o
C)
Operating Humidity 10% ~ 90%
Electric Lock output < / = 3A
Alarm output < / = 20A
Short circuit protection time < / = 100 μ S
Activation time 0 ~ 99 seconds (adjustable)
Size
4.74in (120mm) x 2.2in (56mm) x 0.71in (18mm)
Weight
