Technical Data
Interfaces TS1 / TS2 / TS3 / TS4 / TS5 / TS6
Design 2 spring-type terminals each
Assignment as inputs
Admissible temperature probe Temperature sensor Pt 1000
Optional assignment of
TS3 / TS4 to the impeller sensor DFZ 1-100 pulses/litre
Optional assignment as
output on TS4 PWM signal 100Hz...2kHz or
analogue output 0...10V, max. 10mA
Interface TS7 / TS8
Design 2 spring-type terminals each
Assignment as output PWM signal 100Hz...2kHz
analogue output 0...10V, max. 10mA
Triac outputs RO1 / RO2
Design 3 spring-type terminals each, PE, N and L
Output voltage [VAC] 230 ±10%
Output power max.
per output [VA] 200
Output current max.
per output [A] 1
Switching output REL: change-over contact
Design 3 spring-type terminals
Switching voltage max. [V] 253
Switching capacity max. [VA] 230
Switching current max. [A] 1
Interface for analogue Vortex ow sensors
Design Plug connector
