Location of controls
1) Dust cover
2) CD play/pause button
3) CD stop
button
4) CD skip up
/down button
5) Rep/Ran button
6) Program button
7) Volume up/down button
8) Power button
9) CD tray
10) CD tray open button
11) 3.5mm stereo headphone jack
12) Function selector
13) Radio band selector
14) Power LED indicator
15) LCD display
16) FM stereo LED indicator
17) Dial scale
18) Tuning knob
19) Tape forward / Eject button
20) Cassette door cover
21) Spindle adaptor
22) Turntable speed selector
23) Tone arm rest
24) Line out socket
25) Speaker jack
26) FM antenna
27) Auto stop on/off switch
28) AC line cord
Caution:
Usage of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified service personnel.
Precautions for use
Installation
• Unpack all parts and remove protective material.
• Do not connect the unit to AC outlet before checking the AC voltage and before all other connections have been
made.
• Do not cover any vents and make sure that there is a space of several inches around the unit for ventilation.
-3-
