Encore ENAT-OD7 User Manual

Introducon:
Congratulaons! You have just purchased another quality product
for your Wi-Fi wireless networking accessory.
Encore’s ENAT-OD7 Omni Direconal Wireless Antenna expands
more than 3 mes wireless coverage and gives more boosng
power compare to a regular antenna.
With 7dBi antenna power, your wireless connecon is reliably
stronger and almost eliminates most dead-spots found on a
regular antenna.
No more worries on where to place your wireless devices to get
the best recepon because almost all places within the ENAT-OD7
range get quality recepons.
Encore strongly recommends that you follow direcons found in
this user manual for the most and effecve usage of your antenna.
ENAT-OD7 is compable with 802.11 b, g, and n wireless products
with detachable SMA connector.
Caring your Omni Direconal Wireless Antenna:
•Do not expose the Encore ENAT-OD7 Wi-Fi Antenna to any
extreme temperatures.
•Do not use the ENAT-OD7 Omni Direconal Wireless Antenna
in extremely humid surroundings.
•Protect the antenna against powerful shocks or jolts as it may
damage the antenna structures and electronic components.
•Never aempt to open the antenna yourself-There are no
end-user components inside. Opening the antenna by any
unauthorized repair service or person voids the warranty.
Package Contents
•User’s Manual - x1
•ENAT-OD7 Omni Direconal Wireless Antenna - x1
Installaon:
•If hooking up to the wireless LAN card on a computer, the
computer must be shutdown down and unplug from the power
outlet. If hooking up to the wireless router or access point the
power adapter must be unplugged.
•Unscrew the exisng antenna in a counter-clockwise direcon.
•Replace with Encore’s ENAT-OD7 antenna by screwing it in a
clockwise direcon.
•Power-on the device (Computer for LAN card / Router or
Access Point).
Specificaons
•Amplificaon: 7 dBi Omni Direconal Wireless Antenna
•Supports: IEEE 802.11b, 802.11g and 802.11n
•Connector: RP SMA
•Frequency range: 2.4
~
2.4835 GHz
•VSWR rao: ≤ 2.0
•Impedance: 50 Ohm nominal

Encore ENAT-OD7 Specifications

General

Brand	Encore
Model	ENAT-OD7
Category	Antenna
Language	English
