Encore ENCA-CCDN User Manual

ENCA-CCDN
:NPENV2
All Weather CCD Security Camera with Night Vision
www.encore-usa.com
INTRODUCTION:
Encore’s ENCA-CCDN All Weather Color CCD Security Camera with Night Vision is a
high quality indoor and outdoor camera for your Surveillance security DVR System. Safe
to place outdoor on any weather type, it features water and lightning proof. It uses a 1/4“
Sharp High Resolution CCD image sensor for superior video quality. Equipped with 24
Infra Read LED’s for clear and crisp night vision video recording even at total darkness. It
perfectly fits the Encore surveillance products such as the ENXDVR-4C, ENDSS-R4D8
and all future Encore Video Surveillance Kits.
SPECIFICATIONS:
SPECIFICATION VALUE
Image Sensor 1/4" Sharp CCD
Total Pixels 512(H) x 492(V)
Sensing Area 2.7mm x 3.6mm
Lens 3.6 mm M12 Lens (Optional)
Scanning System 2:1 Interlaced
Sync. System Internal
Resolution 420 TV Lines
Electronics Shutter 1/60 - 1/100,000 sec
Minimum Illumination 1.0Lux/F1.2, 0Lux ( IR on )
Lens 3.6 mm
Angle View 90°
Mini Focal Distance 20 cm
AGC Built-in
White Balance Auto
Gain Control Auto
S/N Ratio 48 dB (AGC Off)
Elctronic Shutter Auto, 1/50 (1/60) - 1/100,000 sec
Video Output 1.0Vp-p Composite Video Output, 75Ohm
IR LED
24 Units Infrared LED ( 5mm / 850mm)
IR Distance In Effect 10-15 m
IR Illumination 0Lux (IR On)
Environmental Resistance 1P66 (Waterproof)
Operating Temperature -4°F to 122°F ('-20
℃
to 50
℃
)
Dimension 11.8x10.3x6 cm
Power Consumption 12VDC / 120mA (IR On 320mA)
Weight 270 g (arpoximate)
Regulations & Certifications FCC, CE, RoHS
