Encore ENH916P-NWY Specifications

Applications
. High-speed Internet access sharing
. Video-On-Demand
. Telecommuting
. Distance learning
. Remote workgroup networking
. Corporate LAN access (VPN)
. Video conferencing
Specifications
Data Transfer Rates 10Mbps and 100Mbps
Protocol
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
IEEE 802.3x Full Duplex Flow Control
Connector RJ-45 x 16
Transmission Method Store and Forward
MAC Address Table 4K
Switch Fabric 3.2Gbps
Packet Forwarding 2.38Mbps
Power Consumption 12W
Dimensions (app.) 270mm (length) x 97mm (width) x 32mm (height)
Net Weight (app.) 500 g
Operating Temperature
0°C ~ 45°C ambient
Humidity 5 % ~ 95 % (non-condensing)
Storage Temperature
0°C ~ 70°C
Regulations FCC part 15 Class A, CE
V.1.0

Encore ENH916P-NWY Specifications

General

Standard	IEEE802.3, 10BASE-T IEEE802.3u, 100BASE-TX IEEE802.3x Full Duplex operation and Flow Control
LED indications	System Power Port Link/Activity
Emission	FCC Class A, CE, VCCI
Interface	16 * RJ-45 NWay switching ports
Cable Connections	RJ-45 (10BASE-T) : Category 3, 4, 5 UTP/STP RJ-45 (100BASE-TX) : Category 5 UTP/STP
Network Data Rate	Auto-negotiation (10Mbps, 100Mbps)
Transmission Mode	Auto-negotiation (Full-duplex, Half-duplex)
MAC Address Table	8K MAC entries
Filtering/Forwarding Rate	10Mbps: 14, 880pps/14, 880pps 100Mbps: 148, 800pps/148, 800pps
System Buffer Memory	156K Bytes
Operating Temperature	0 ~ 40 C (32 ~ 104 F) 0 0 0 0
Operating Humidity	10% - 90%
Power Supply	External linear power adapter (12V/1A)
