ENDURO
®
autoSteady 28
Ref: AS101-UM-TKI-0114-Rev. A
TABLE OF CONTENTS
Package contents (Parts list) Page 28
Introduction Page 29
Intended use Page 29
Specifications Page 29
Installation - safety guidelines Page 29
Installation - mechanical components Page 30
Installation - electrical/electronic components Page 31
Operation - safety guidelines Page 33
Operation - remote control Page 34
Operation - electronic control unit Page 35
Operation - getting started Page 36
Operation - emergency draw back function Page 38
Operation – manually operation Page 38
Maintenance Page 39
Trouble-shooting Page 39
PACKAGE CONTENTS
Ref Qte Description
1 2 Motorized spindle (V1)
2 2 Motorized spindle (V2)
3 1 Level gauge
4 1 User manual
5 1 Remote control handset with lanyard
6 1 Electronic control unit
7 1 Tool for removing the spring-pin
8 4 Bearing
9 4 Pin for fixing the 19mm hex head
10 4 19mm hex head
11 4 Ground support plate
12 2 Screw – M5x40
13 42 Screw – M4x15
14 10 Cable trunking P-clip 19.2mm
15 32 Cable P-clip 10.4mm
16 3 Cable number marker (A,B,C,D)
17 20 Cable tie
18 1 Cable for automatically draw back function
19 1 Positive (+) red battery cable 1.8m including fuse holder & 20A fuse
20 1 Black battery cable(-) 1.6m
21 2 Battery terminal connector 6mmØ
22 4 Battery terminal connector 8mmØ
23 12 Spade fork connector
24 1 Battery isolation switch, cover & key
25 2 Rubber isolation shell for battery isolation switch
26 2 Convoluted cable trunking
27 8 Flange nut - M8
