EN
DURO
®
BT1201 4
Ref: BT1201-UM-TKI-0314-Rev.A.
Introduction
Thank you for purchasing the EN
DURO
®
BT1201 12Volt battery tester. The
EN
DURO
®
BT1201 battery tester is member of the family of advanced car- and
caravan accessories manufactured by EN
DURO
®
.
Intended use
For checking and testing the 12V battery.
• Ideal for a permanent installation in caravan, motor home or boat
• Display with 4 LEDs
• Including O-rings for a permanent connection to the battery terminals
• Fixation of the battery tester by double-sided tape
• Battery tester is only activated by pressing the test button, so no current leakage
• Suitable on 12V normal lead acid, sealed lead acid, gel, AGM and deep cycle batteries
Technical specifications
Type EN
DURO
®
BT1201
Voltage range 8-16Volt
Current consumption 70mA max.
Battery type Lead acid, AGM, Gel
Weight 50Gram
Measurements 60x50x20mm
Ambient Temperature 0°C to +40°C
Safety instructions
• This battery tester is only suitable for 12V normal lead acid, sealed lead acid, gel,
AGM and deep cycle batteries.
• Do not disassemble battery tester, incorrect reassemble may result in electric shock
or fire.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Connections
Attach the cable O-ring of the red cable to the plus point (+) of the battery and the cable
O-ring of the black cable to the minus point (-) of the battery.
Function of the LEDs
Push the button to check the battery condition.
The LEDs will show the battery voltage and battery condition:
LED BATTERY VOLTAGE CONDITION
RED 10,5V -11,5V Battery needs to be charged
YELLOW-1 11,6-12V Battery needs to be charged
YELLOW-2 12,1V -12,5V
GREEN > 12,6V Battery fully charged
Environmental protection
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your local authority or retailer for
recycling advice.
