Analogue-addressable fire detectors
3
A
Detector
H
Cover removing hooks
B
Base
I
Optical chambre removing
hooks
C
Red/yellow/green LED
L
“+” terminal
D
Optical chamber
M
“-” terminals
E
Thermal probe
N
“R” terminal
F
Technical specifications/
serial-number sticker
O
Short-circuit reed
G
Removable serial-number
stickers
P
Screw locations
A
C
E
F
I
L
M
N
O
B
D
A
C
H
H
D
E
C
P
P
G
I
