Assembly Instruction
Step 1
Attach the front (16) and rear feet (12) to the frame using
the nuts (8), washer (9) and bolts (10).
Step 2
Attach the handlebar post (23) inserting into the head
tube on the frame. Using knob to adjust and tighten the
height in proper position. Then attached handlebar slider
(21) on the handlebar post (23), use release lever (22) to
adjust and tighten the handlebar in proper position.
Step 3
Insert the seat post (42) into the frame’s seat tube.
Attach the saddle (1) into seat slider (41). Insert the seat
slider (41) into the seat post (42) and fix. Using knob (4)
adjusts and tightens the height in proper position.
