Energetics ET 12.0 ERGOMETER - Page 6

6
NO. DESCRIPTION SIZE Q'TY NO. DESCRIPTION SIZE Q'TY
1 BASE FRAME 1 43 PLASTIC CAP 8
2 UPRIGHT TUBE WELDMENT 1 44 CHAIN COVER (L) 1
3 FIX HANDLEBAR 1 45 CHAIN COVER (R) 1
4 HANDLE BAR (L) 1 46 TURNING PEDAL DISC 2
5 HANDLE BAR (R) 1 47 DECORATE COVER 1
6 LOWER SWIVEL HANDLE BAR 2 48 PLUG AXLE SUPPORT 14
7 SWIVEL TUBE 2 49 PLASTIC INSERT 2
8 PEDAL TUBE WELDMENT (L) 1 50 OVAL CAP 2
9 PEDAL TUBE WELDMENT (R) 1 51 BELT 1
10 FRONT&REAR STABILIZER 2 52 SET SCREW M10x28mm 4
11 TURNING PEDAL DISC TUBE 2 53 FIX HANDLEBAR FOAM GRIPS 1
12 AXLE FOR PULLEY 1 54 HANDLEBAR FOAM GRIPS 2
13 BUSH FOR AXLE 1 55 FIX HANDLEBAR FOAM GRIPS 2
14 AXLE SUPPORT 1 56 BUSHING 2
15 BUSH FOR LOWER H.B 2 57 PEDAL KNOB 4
16 SCREW M8x15 mm 10 58 SCREW #6x12mm 1
17 SCREW #8-32 UNC 2 59 WASHER DIA. 20 2
18 SCREW M8x50mm 4 60 SENSOR BRACKET 1
19 SCREW (NYLON) M8x20mm 2 61 MAGNET 1
20 SCREW M8x90mm 2 62 SCREW M5x12mm 2
21 ALLEN HEAD BOLT M8x53mm 4 63 CONTROL BOARD 1
22 ALLEN HEAD BOLT M6x14mm 5 64 COMPUTER 1
23 SCREW M4x10mm 2 65 ADAPTOR 1
24 SCREW M5x16mm 16 66 PULSE GRIP UNIT 2
25 SCREW M5x30mm 8 67 PULSE WIRE 1
26 HEXAGON NUT M8 4 68 COMPUTER CABLE (UPPER) 1
27 NYLON NUT M8 3 69
SERVO MOTOR &COMPUTER
CABLE (LOWER)
1
28 WASHER M8x38 4 70 SENSOR WIRE 1
29 WASHER M8x16 15 71 FLYWHEEL 1
30 WASHER CURVE M8 4 72 SCREW M4x16mm 2
31 SPRING WASHER M8 6 73 DC CABLE 1
32 BEARING <6004ZZ> 2 74 TURNING PLATE COVER 2
33 CLIP C20 2 75 IDLE WHEEL BRACKET 1
34 END CAP 1 76 BRACKET OF SPRING 1
35 FRONT STABILIZER COVER(L) 1 77 IDLE WHEEL 1
36 FRONT STABILIZER COVER(R) 1 78 SCREW M8x25mm 1
37 REAR STABILIZER COVER 2 79 WASHER M6 4
38 KNOB 2 80 NYLON WASHER M10 2
39 PEDAL (L) 1 81 CLIP C12 1
40 PEDAL (R) 1 82 BEARING <6001ZZ> 1
41 HANDLEBAR END CAP 2 83 SPRING (BIG) 1
42 FIX HANDLEBAR END CAP 2 84 WIRE OF FLYWHEEL 1
Part list – ET 12.0 Ergometer - 2007
