8
Assembly instruction
Step 1
A
(x4)
(x4)
C
M6*1*45L
21R
21L
11
D14*D6.5*0.8T
D40*M6*12
2
73
77
7
12
20 21L 1
9
3
(A)
1. Assemble the front stabilizer (2) and the rear stabilizer (3) to the mainframe (1) using the Allen
bolts (9), spring washers (7) and flat washers (12).
2. Fix the pedals (21L&21R) onto the pedal support tube (11) by means of square neck bolt (20), flat
washer (73) and knob (77).
3. Adjust the knob that under the foot cap (4) could help to keep balance.
