RSL Torque Wrench
7.2.1 Imperial System Table - RSL Hexagon Cassette [continued]
(see Fig. 7.1-1 for locations of dimensions AF, R, L, H and W)
Size
Model
AF Hex
size inch
(Max)
(R)
inch
(L)
inch
(H)
inch
(W)
inch
Weight
lbs
RLP11 (to be used with Torque Wrench Drive RSL11000)
RLP11303 3
3
/16 2.60 11.71 2.50 8.64 16.6
RLP11085M - 2.60 11.71 2.50 8.64 16.6
RLP11304 3
1
/4 2.60 11.71 2.50 8.64 16.6
RLP11305 3
5
/16 2.60 11.71 2.50 8.64 16.6
RLP11306 3
3
/8 2.60 11.71 2.50 8.64 16.6
RLP11307 3
7
/16 2.60 11.71 2.50 8.64 16.6
RLP11308 3
1
/2 2.60 11.71 2.50 8.64 16.6
RLP11090M - 2.88 11.89 2.50 8.92 17.2
RLP11309 3
9
/16 2.88 11.89 2.50 8.92 17.2
RLP11310 3
5
/8 2.88 11.89 2.50 8.92 17.2
RLP11311 3
11
/16 2.88 11.89 2.50 8.92 17.2
RLP11312 3
3
/4 2.88 11.89 2.50 8.92 17.2
RLP11313 3
13
/16 2.88 11.89 2.50 8.92 17.2
RLP11314 3
7
/8 2.88 11.89 2.50 8.92 17.2
RLP11315 3
15
/16 2.98 12.00 2.50 9.03 16.4
RLP11400 4 2.98 12.00 2.50 9.03 16.4
RLP11401 4
1
/16 2.98 12.00 2.50 9.03 16.4
RLP11402 4
1
/8 2.98 12.00 2.50 9.03 16.4
RLP11404 4
1
/4 2.98 12.00 2.50 9.03 16.4
RLP11405 4
5
/16 3.25 12.27 2.50 9.30 17.6
RLP11408 4
1
/2 3.25 12.27 2.50 9.30 17.6
RLP11410 4
5
/8 3.25 12.27 2.50 9.30 17.6
RLP19 (to be used with Torque Wrench Drive RSL19000)
RLP19215 2
15
/16 2.45 12.72 2.75 9.44 21.5
RLP19300 3 2.45 12.72 2.75 9.44 21.5
RLP19301 3
1
/16 2.45 12.72 2.75 9.44 21.5
RLP19302 3
1
/8 2.45 12.72 2.75 9.44 21.5
RLP19303 3
3
/16 2.77 13.04 2.75 9.76 22.6
RLP19085M - 2.77 13.04 2.75 9.76 22.6
RLP19304 3
1
/4 2.77 13.04 2.75 9.76 22.6
RLP19305 3
5
/16 2.77 13.04 2.75 9.76 22.6
RLP19306 3
3
/8 2.77 13.04 2.75 9.76 22.6
RLP19307 3
7
/16 2.77 13.04 2.75 9.76 22.6
RLP19308 3
1
/2 2.77 13.04 2.75 9.76 22.6
RLP19090M - 2.95 13.22 2.75 9.94 23.8
RLP19309 3
9
/16 2.95 13.22 2.75 9.94 23.8
RLP19310 3
5
/8 2.95 13.22 2.75 9.94 23.8
RLP19311 3
11
/16 2.95 13.22 2.75 9.94 23.8
RLP19312 3
3
/4 2.95 13.22 2.75 9.94 23.8
RLP19313 3
13
/16 2.95 13.22 2.75 9.94 23.8
RLP19314 3
7
/8 2.95 13.22 2.75 9.94 23.8
RLP19315 3
15
/16 3.30 13.57 2.75 10.28 25.3
RLP19400 4 3.30 13.57 2.75 10.28 25.3
RLP19401 4
1
/16 3.30 13.57 2.75 10.28 25.3
RLP19402 4
1
/8 3.30 13.57 2.75 10.28 25.3
RLP19403 4
3
/16 3.30 13.57 2.75 10.28 25.3
RLP19404 4
1
/4 3.30 13.57 2.75 10.28 25.3
RLP19405 4
5
/16 3.44 13.71 2.75 10.43 25.6
RLP19406 4
3
/8 3.44 13.71 2.75 10.43 25.6
RLP19407 4
7
/16 3.44 13.71 2.75 10.43 25.6
RLP19408 4
1
/2 3.44 13.71 2.75 10.43 25.6
