27
RSL Torque Wrench
7.2.1 Imperial System Table - RSL Hexagon Cassette [continued]
(see Fig. 7.1-1 for locations of dimensions AF, R, L, H and W)
Size
Model
AF Hex
size inch
(Max)
(R)
inch
(L)
inch
(H)
inch
(W)
inch
Weight
lbs
RLP19 (to be used with Torque Wrench Drive RSL19000)
RLP19115M - 3.44 13.71 2.75 10.43 25.6
RLP19409 4
9
/16 3.44 13.71 2.75 10.43 25.6
RLP19410 4
5
/8 3.44 13.71 2.75 10.43 25.6
RLP28 (to be used Torque Wrench Drive RSL28000)
RLP28302 3
1
/8 2.56 14.36 3.00 10.54 27.6
RLP28303 3
3
/16 2.56 14.36 3.00 10.54 27.6
RLP28085M - 2.56 14.36 3.00 10.54 27.6
RLP28304 3
1
/4 2.56 14.36 3.00 10.54 27.6
RLP28305 3
5
/16 2.56 14.36 3.00 10.54 27.6
RLP28306 3
3
/8 2.56 14.36 3.00 10.54 27.6
RLP28307 3
7
/16 2.56 14.36 3.00 10.54 27.6
RLP28308 3
1
/2 2.56 14.36 3.00 10.54 27.6
RLP28090M - 2.92 14.36 3.00 10.77 28.8
RLP28309 3
9
/16 2.92 14.36 3.00 10.77 28.8
RLP28310 3
5
/8 2.92 14.36 3.00 10.77 28.8
RLP28311 3
11
/16 2.92 14.36 3.00 10.77 28.8
RLP28312 3
3
/4 2.92 14.36 3.00 10.77 28.8
RLP28313 3
13
/16 2.92 14.36 3.00 10.77 28.8
RLP28314 3
7
/8 2.92 14.36 3.00 10.77 28.8
RLP28315 3
15
/16 3.29 14.47 3.00 11.14 31.7
RLP28400 4 3.29 14.47 3.00 11.14 31.7
RLP28401 4
1
/16 3.29 14.47 3.00 11.14 31.7
RLP28402 4
1
/8 3.29 14.47 3.00 11.14 31.7
RLP28403 4
3
/16 3.29 14.47 3.00 11.14 31.7
RLP28404 4
1
/4 3.29 14.47 3.00 11.14 31.7
RLP28405 4
5
/16 3.43 14.61 3.00 11.28 31.5
RLP28406 4
3
/8 3.43 14.61 3.00 11.28 31.5
RLP28407 4
7
/16 3.43 14.61 3.00 11.28 31.5
RLP28408 4
1
/2 3.43 14.61 3.00 11.28 31.5
RLP28115M - 3.43 14.61 3.00 11.28 31.5
RLP28409 4
9
/16 3.43 14.61 3.00 11.28 31.5
RLP28410 4
5
/8 3.43 14.61 3.00 11.28 31.5
RLP28412 4
3
/4 3.65 14.83 3.00 11.50 33.5
RLP28123M - 3.65 14.83 3.00 11.50 33.5
RLP28414 4
7
/8 3.65 14.83 3.00 11.50 33.5
RLP28500 5 3.65 14.83 3.00 11.50 33.5
RLP28502 5
1
/8 3.79 14.97 3.00 11.64 33.2
RLP28503 5
3
/16 3.79 14.97 3.00 11.64 33.2
RLP28504 5
1
/4 3.79 14.97 3.00 11.64 33.2
RLP28506 5
3
/8 3.79 14.97 3.00 11.64 33.2
RLP28508 5
1
/2 4.05 15.23 3.00 11.90 33.5
RLP28509 5
9
/16 4.05 15.23 3.00 11.90 33.5
RLP28510 5
5
/8 4.05 15.23 3.00 11.90 33.5
RLP28512 5
3
/4 4.05 15.23 3.00 11.90 33.5
RLP28514 5
7
/8 4.22 15.48 3.00 12.15 34.5
RLP28600 6 4.22 15.48 3.00 12.15 34.5
RLP28602 6
1
/8 4.22 15.48 3.00 12.15 34.5
