Enerpac RSL2 - Hexagon Cassette Specifications (Metric)

28
RSL Torque Wrench
7.2.2 Metric System Table - RSL Hexagon Cassette
(see Fig. 7.1-1 for locations of dimensions AF, R, L, H and W)
Size
Model
AF Hex
size mm
(Max)
(R)
mm
(L)
mm
(H)
mm
(W)
mm
Weight
kg
RLP1 (to be used with Torque Wrench Drive RSL1500)
RLP1014 – 20.1 152.4 31.8 110.0 1.0
RLP1101 26 24.1 153.7 31.8 114.3 1.0
RLP1102 – 26.2 155.4 31.8 116.1 1.0
RLP1103 30 26.2 155.4 31.8 116.1 1.0
RLP1104 32 26.2 155.4 31.8 116.1 1.0
RLP1105 33 29.2 158.5 31.8 119.1 1.1
RLP1106 35 29.2 158.5 31.8 119.1 1.1
RLP1107 36 29.2 158.5 31.8 119.1 1.1
RLP1108 38 33.3 162.8 31.8 123.4 1.2
RLP1109 – 33.3 162.8 31.8 123.4 1.2
RLP1110 41 33.3 162.8 31.8 123.4 1.2
RLP1111 – 35.6 164.8 31.8 125.5 1.2
RLP1112 – 35.6 164.8 31.8 125.5 1.2
RLP1113 46 35.6 164.8 31.8 125.5 1.2
RLP1114 – 37.6 167.1 31.8 127.8 1.2
RLP1115 – 37.6 167.1 31.8 127.8 1.2
RLP1200 50 37.6 167.1 31.8 127.8 1.2
RLP1201 – 40.1 169.7 31.8 130.3 1.2
RLP1202 40.1 169.7 31.8 130.3 1.2
RLP1203 55 40.1 169.7 31.8 130.3 1.2
RLP1204 – 43.2 172.5 31.8 133.1 1.3
RLP1205 – 43.2 172.5 31.8 133.1 1.3
RLP1206 60 43.2 172.5 31.8 133.1 1.3
RLP3 (to be used with Torque Wrench Drive RSL3000)
RLP3105 33 30.0 193.5 35.1 139.4 1.6
RLP3106 35 30.0 193.5 35.1 139.4 1.6
RLP3107 36 30.0 193.5 35.1 139.4 1.6
RLP3108 38 33.5 197.4 35.1 143.0 1.8
RLP3109 – 33.5 197.4 35.1 143.0 1.8
RLP3110 41 33.5 197.4 35.1 143.0 1.8
RLP3111 – 37.3 199.9 35.1 146.8 1.8
RLP3112 – 37.3 199.9 35.1 146.8 1.8
RLP3113 46 37.3 199.9 35.1 146.8 1.8
RLP3114 – 40.6 204.2 35.1 150.4 2.0
RLP3115 – 40.6 204.2 35.1 150.4 2.0
RLP3200 50 40.6 204.2 35.1 150.4 2.0
RLP3201 – 44.7 207.3 35.1 154.4 2.1
RLP3202 – 44.7 207.3 35.1 154.4 2.1
RLP3203 55 44.7 207.3 35.1 154.4 2.1
RLP3204 – 46.7 209.6 35.1 156.2 2.2
RLP3205 – 46.7 209.6 35.1 156.2 2.2
RLP3206 60 46.7 209.6 35.1 156.2 2.2
RLP3207 62 49.5 206.8 35.1 159.0 2.1
RLP3208 63 49.5 206.8 35.1 159.0 2.1
RLP3209 65 49.5 206.8 35.1 159.0 2.1
RLP3210 – 51.8 209.0 35.1 161.5 2.0
RLP3211 – 51.8 209.0 35.1 161.5 2.0
RLP3212 70 51.8 209.0 35.1 161.5 2.0
RLP3213 – 54.9 211.8 35.1 166.1 2.1
RLP3214 – 54.9 211.8 35.1 166.1 2.1
RLP3215 75 54.9 211.8 35.1 166.1 2.1
