RSL Torque Wrench
7.2.2 Metric System Table - RSL Hexagon Cassette [continued]
(see Fig. 7.1-1 for locations of dimensions AF, R, L, H and W)
Size
Model
AF Hex
size mm
(Max)
(R)
mm
(L)
mm
(H)
mm
(W)
mm
Weight
kg
RLP5 (to be used with Torque Wrench Drive RSL5000)
RLP5111 – 40.9 230.6 44.5 165.6 3.0
RLP5112 – 40.9 230.6 44.5 165.6 3.0
RLP5113 46 40.9 230.6 44.5 165.6 3.0
RLP5114 – 40.9 230.6 44.5 165.6 3.0
RLP5115 – 40.9 230.6 44.5 165.6 3.0
RLP5200 50 40.9 230.6 44.5 165.6 3.0
RLP5201 – 43.4 233.2 44.5 168.1 2.9
RLP5202 – 43.4 233.2 44.5 168.1 2.9
RLP5203 55 43.4 233.2 44.5 168.1 2.9
RLP5204 – 47.5 237.2 44.5 172.2 3.2
RLP5205 – 47.5 237.2 44.5 172.2 3.2
RLP5206 60 47.5 237.2 44.5 172.2 3.2
RLP5207 – 51.1 240.8 44.5 175.8 3.2
RLP5208 63 51.1 240.8 44.5 175.8 3.2
RLP5209 65 51.1 240.8 44.5 175.8 3.2
RLP5210 – 54.9 244.6 44.5 179.6 3.4
RLP5211 – 54.9 244.6 44.5 179.6 3.4
RLP5212 70 54.9 244.6 44.5 179.6 3.4
RLP5213 – 56.9 246.6 44.5 181.6 3.4
RLP5214 – 56.9 246.6 44.5 181.6 3.4
RLP5215 75 56.9 246.6 44.5 181.6 3.4
RLP5300 – 57.4 247.1 44.5 182.1 3.3
RLP5301 – 57.4 247.1 44.5 182.1 3.3
RLP5302 80 57.4 247.1 44.5 182.1 3.3
RLP8 (to be used with Torque Wrench Drive RSL8000)
RLP8206 60 47.5 242.1 57.2 177.8 4.0
RLP8207 62 51.1 245.6 57.2 181.1 4.1
RLP8208 63 51.1 245.6 57.2 181.1 4.1
RLP8209 65 51.1 245.6 57.2 181.1 4.1
RLP8210 – 54.9 249.4 57.2 184.9 4.4
RLP8211 – 54.9 249.4 57.2 184.9 4.4
RLP8212 70 54.9 249.4 57.2 184.9 4.4
RLP8213 – 56.9 251.5 57.2 187.5 4.4
RLP8214 – 56.9 251.5 57.2 187.5 4.4
RLP8215 75 56.9 251.5 57.2 187.5 4.4
RLP8300 – 57.4 252.0 57.2 187.7 4.2
RLP8301 – 57.4 252.0 57.2 187.7 4.2
RLP8302 80 57.4 252.0 57.2 187.7 4.2
RLP11 (to be used Torque Wrench Drive RSL11000)
RLP11207 62 50.3 254.0 63.5 204.0 6.4
RLP11208 – 50.3 254.0 63.5 204.0 6.4
RLP11209 65 50.3 254.0 63.5 204.0 6.4
RLP11210 – 55.6 284.5 63.5 209.0 6.7
RLP11211 – 55.6 284.5 63.5 209.0 6.7
RLP11212 70 55.6 284.5 63.5 209.0 6.7
RLP11213 58.2 287.3 63.5 211.8 6.7
RLP11214 – 58.2 287.3 63.5 211.8 6.7
RLP11215 75 58.2 287.3 63.5 211.8 6.7
RLP11300 – 61.7 290.6 63.5 215.1 6.9
RLP11301 – 61.7 290.6 63.5 215.1 6.9
RLP11302 80 61.7 290.6 63.5 215.1 6.9
