RSL Torque Wrench
7.2.2 Metric System Table - RSL Hexagon Cassette [continued]
(see Fig. 7.1-1 for locations of dimensions AF, R, L, H and W)
Size
Model
AF Hex
size mm
(Max)
(R)
mm
(L)
mm
(H)
mm
(W)
mm
Weight
kg
RLP11 (to be used with Torque Wrench Drive RSL11000)
RLP11303 – 66.0 297.4 63.5 219.5 7.5
RLP11085M 85 66.0 297.4 63.5 219.5 7.5
RLP11304 – 66.0 297.4 63.5 219.5 7.5
RLP11305 – 66.0 297.4 63.5 219.5 7.5
RLP11306 – 66.0 297.4 63.5 219.5 7.5
RLP11307 – 66.0 297.4 63.5 219.5 7.5
RLP11308 – 66.0 297.4 63.5 219.5 7.5
RLP11090M 90 73.2 302.0 63.5 226.6 7.8
RLP11309 – 73.2 302.0 63.5 226.6 7.8
RLP11310 – 73.2 302.0 63.5 226.6 7.8
RLP11311 – 73.2 302.0 63.5 226.6 7.8
RLP11312 95 73.2 302.0 63.5 226.6 7.8
RLP11313 – 73.2 302.0 63.5 226.6 7.8
RLP11314 – 73.2 302.0 63.5 226.6 7.8
RLP11315 100 75.7 304.8 63.5 229.4 7.4
RLP11400 – 75.7 304.8 63.5 229.4 7.4
RLP11401 – 75.7 304.8 63.5 229.4 7.4
RLP11402 105 75.7 304.8 63.5 229.4 7.4
RLP11404 – 75.7 304.8 63.5 229.4 7.4
RLP11405 110 82.6 311.7 63.5 236.2 8.0
RLP11408 – 82.6 311.7 63.5 236.2 8.0
RLP11410 – 82.6 311.7 63.5 236.2 8.0
RLP19 (to be used with Torque Wrench Drive RSL19000)
RLP19215 75 62.2 323.1 69.9 239.8 9.8
RLP19300 – 62.2 323.1 69.9 239.8 9.8
RLP19301 – 62.2 323.1 69.9 239.8 9.8
RLP19302 80 62.2 323.1 69.9 239.8 9.8
RLP19303 – 70.4 331.2 69.9 247.9 10.3
RLP19085M 85 70.4 331.2 69.9 247.9 10.3
RLP19304 – 70.4 331.2 69.9 247.9 10.3
RLP19305 – 70.4 331.2 69.9 247.9 10.3
RLP19306 – 70.4 331.2 69.9 247.9 10.3
RLP19307 – 70.4 331.2 69.9 247.9 10.3
RLP19308 – 70.4 331.2 69.9 247.9 10.3
RLP19090M 90 74.9 335.8 69.9 252.5 10.8
RLP19309 – 74.9 335.8 69.9 252.5 10.8
RLP19310 – 74.9 335.8 69.9 252.5 10.8
RLP19311 – 74.9 335.8 69.9 252.5 10.8
RLP19312 95 74.9 335.8 69.9 252.5 10.8
RLP19313 – 74.9 335.8 69.9 252.5 10.8
RLP19314 – 74.9 335.8 69.9 252.5 10.8
RLP19315 100 83.8 344.7 69.9 261.1 11.5
RLP19400 – 83.8 344.7 69.9 261.1 11.5
RLP19401 – 83.8 344.7 69.9 261.1 11.5
RLP19402 105 83.8 344.7 69.9 261.1 11.5
RLP19403 – 83.8 344.7 69.9 261.1 11.5
RLP19404 – 83.8 344.7 69.9 261.1 11.5
RLP19405 110 87.4 348.2 69.9 264.9 11.6
RLP19406 – 87.4 348.2 69.9 264.9 11.6
RLP19407 – 87.4 348.2 69.9 264.9 11.6
RLP19408 – 87.4 348.2 69.9 264.9 11.6
