Enerpac RSL2 - Page 31

31
RSL Torque Wrench
7.2.2 Metric System Table - RSL Hexagon Cassette [continued]
(see Fig. 7.1-1 for locations of dimensions AF, R, L, H and W)
Size
Model
AF Hex
size mm
(Max)
(R)
mm
(L)
mm
(H)
mm
(W)
mm
Weight
kg
RLP19 (to be used with Torque Wrench Drive RSL19000)
RLP19115M 115 87.4 348.2 69.9 264.9 11.6
RLP19409 – 87.4 348.2 69.9 264.9 11.6
RLP19410 – 87.4 348.2 69.9 264.9 11.6
RLP28 (to be used Torque Wrench Drive RSL28000)
RLP28302 80 65.0 364.7 76.2 267.7 12.5
RLP28303 – 65.0 364.7 76.2 267.7 12.5
RLP28304 – 65.0 364.7 76.2 267.7 12.5
RLP28305 – 65.0 364.7 76.2 267.7 12.5
RLP28085M 85 65.0 364.7 76.2 267.7 12.5
RLP28306 – 65.0 364.7 76.2 267.7 12.5
RLP28307 – 65.0 364.7 76.2 267.7 12.5
RLP28308 – 65.0 364.7 76.2 267.7 12.5
RLP28090M 90 74.2 364.7 76.2 273.6 13.1
RLP28309 – 74.2 364.7 76.2 273.6 13.1
RLP28310 – 74.2 364.7 76.2 273.6 13.1
RLP28311 – 74.2 364.7 76.2 273.6 13.1
RLP28312 95 74.2 364.7 76.2 273.6 13.1
RLP28313 – 74.2 364.7 76.2 273.6 13.1
RLP28314 – 74.2 364.7 76.2 273.6 13.1
RLP28315 100 83.6 367.5 76.2 283.0 14.4
RLP28400 – 83.6 367.5 76.2 283.0 14.4
RLP28401 – 83.6 367.5 76.2 283.0 14.4
RLP28402 105 83.6 367.5 76.2 283.0 14.4
RLP28403 – 83.6 367.5 76.2 283.0 14.4
RLP28404 – 83.6 367.5 76.2 283.0 14.4
RLP28405 110 87.1 371.1 76.2 286.5 14.3
RLP28406 – 87.1 371.1 76.2 286.5 14.3
RLP28407 – 87.1 371.1 76.2 286.5 14.3
RLP28408 – 87.1 371.1 76.2 286.5 14.3
RLP28115M 115 87.1 371.1 76.2 286.5 14.3
RLP28409 – 87.1 371.1 76.2 286.5 14.3
RLP28410 – 87.1 371.1 76.2 286.5 14.3
RLP28412 120 92.7 376.7 76.2 292.1 15.2
RLP28123M 123 92.7 376.7 76.2 292.1 15.2
RLP28414 – 92.7 376.7 76.2 292.1 15.2
RLP28500 – 92.7 376.7 76.2 292.1 15.2
RLP28502 130 96.3 380.2 76.2 295.7 15.1
RLP28503 – 96.3 380.2 76.2 295.7 15.1
RLP28504 – 96.3 380.2 76.2 295.7 15.1
RLP28506 135 96.3 380.2 76.2 295.7 15.1
RLP28508 140 102.9 386.8 76.2 302.3 15.2
RLP28509 – 102.9 386.8 76.2 302.3 15.2
RLP28510 – 102.9 386.8 76.2 302.3 15.2
RLP28512 145 102.9 386.8 76.2 302.3 15.2
RLP28514 150 107.2 393.2 76.2 308.6 15.6
RLP28600 – 107.2 393.2 76.2 308.6 15.6
RLP28602 155 107.2 393.2 76.2 308.6 15.6
