33
RSL Torque Wrench
7.4. Additional BOP Hexagon Cassette Specifications
7.4.1 Imperial System Table - RSL BOP Hexagon Cassette
(see Fig. 7.3-1 for locations of dimensions AF, R, L, H, W and W1)
Size
Model
Max Torque
Nm
AF Hex
size mm
(R)
mm
(L)
mm
(H)
mm
(W)
mm
(W1)
mm
Weight
kg
RLP1
RLP1104SL 508 32 26.2 155.4 116.1 31.75 25.4 1.0
RLP1107SL 892 36 29.2 158.5 119.1 31.75 27.6 1.1
RLP1110SL 1127 41 33.4 162.8 123.4 31.75 25.4 1.2
RLP1113SL 1127 46 35.5 164.8 125.5 31.75 25.4 1.2
RLP1200SL 1127 50 37.7 167.1 127.8 31.75 25.4 1.2
RLP3
RLP3200SL 1836 50 40.6 204.2 150.4 34.95 28.6 2.0
RLP3203SL 2175 55 44.7 207.3 154.4 34.95 28.6 2.1
RLP3206SL 2175 60 46.7 209.6 156.2 34.95 28.6 2.2
RLP3209SL 2175 65 49.5 206.8 159.0 34.95 28.6 2.1
RLP3212SL 2175 70 51.8 209.0 161.5 34.95 28.6 2.0
RLP3215SL 2175 75 54.9 211.8 166.1 34.95 28.6 2.1
RLP5
RLP5212SL 5658 70 54.9 244.6 179.6 44.45 41.15 3.4
RLP5302SL 5658 80 57.4 247.1 182.1 44.45 41.15 3.3
RLP8
RLP8203SL 3372 55 43.4 238.0 173.7 57.15 50.8 3.8
RLP8206SL 4336 60 47.5 242.1 177.8 57.15 50.8 4.0
RLP8209SL 5589 65 51.1 245.6 181.1 57.15 50.8 4.1
RLP8212SL 7575 70 54.9 249.4 184.9 57.15 50.8 4.3
RLP8215SL 7575 75 56.9 251.5 186.9 57.15 50.8 4.4
RLP8302SL 7575 80 57.4 252.0 187.7 57.15 50.8 4.2
RLP8303SL 6427 - 57.4 252.0 187.7 57.15 50.8 4.2
7.4.2 Metric System Table - RSL BOP Hexagon Cassette
(see Fig. 7.3-1 for locations of dimensions AF, R, L, H, W and W1)
Size
Model
Max Torque
Ft.lbs
AF Hex
size inch
(R)
inch
(L)
inch
(H)
inch
(W)
inch
(W1)
inch
Weight
lb
RLP1
RLP1104SL 375
1
1
/4
1.03 6.12 4.57 1.25 1.00 2.25
RLP1107SL 658
1
7
/16
1.15 6.24 4.69 1.25 1.09 2.35
RLP1110SL 831
1
5
/8
1.31 6.41 4.86 1.25 1.00 2.70
RLP1113SL 831
1
13
/16
1.40 6.49 4.94 1.25 1.00 2.70
RLP1200SL 831
2
1048 6.58 5.03 1.25 1.00 2.70
RLP3
RLP3200SL 1354
2
1.60 8.04 5.92 1.38 1.13 4.50
RLP3203SL 1604
2
3
/16
1.76 8.16 6.08 1.38 1.13 4.65
RLP3206SL 1604
2
3
/8
1.84 8.25 6.15 1.38 1.13 4.77
RLP3209SL 1604
2
9
/16
1.95 8.14 6.26 1.38 1.13 4.55
RLP3212SL 1604
2
3
/4
2.04 8.23 6.36 1.38 1.13 4.43
RLP3215SL 1604
2
15
/16
2.16 8.34 6.54 1.38 1.13 4.70
RLP5
RLP5212SL 4173
2
3
/4
2.16 7.07 7.07 1.75 1.62 7.52
RLP5302SL 4173
3
1
/8
2.26 7.17 7.17 1.75 1.62 7.20
RLP8
RLP8203SL 2487
2
3
/16
1.71 6.84 6.84 2.25 2.00 8.45
RLP8206SL 3198
2
3
/8
1.87 7.00 7.00 2.25 2.00 8.90
RLP8209SL 4122
2
9
/16
2.01 7.13 7.13 2.25 2.00 8.95
RLP8212SL 5587
2
3
/4
2.16 7.28 7.28 2.25 2.00 9.56
RLP8215SL 5587
2
15
/16
2.24 7.36 7.36 2.25 2.00 9.62
RLP8302SL 5587
3
1
/8
2.26 7.39 7.39 2.25 2.00 9.29
RLP8303SL 4740
3
3
/16
2.26 7.39 7.39 2.25 2.00 9.29
