38
RSL Torque Wrench
7.8 Torque Settings
7.8.1 Imperial System Pressure/Torque Table
Pump Pressure (psi) Torque (Ft.lbs)
RSL1500 RSL3000 RSL5000 RSL8000 RSL11000 RSL19000 RSL28000
1000 123 290 457 725 961 1957 2298
1200 152 352 564 884 1188 2332 2869
1400 180 414 672 1043 1414 2708 3440
1600 209 476 780 1201 1641 3083 4012
1800 238 538 888 1360 1867 3458 4583
2000 267 600 995 1518 2094 3822 5154
2200 296 662 1103 1677 2320 4209 5725
2400 324 724 1211 1836 2547 4584 6296
2600 353 786 1318 1994 2773 4959 6868
2800 382 848 1426 2153 3000 5334 7439
3000 411 910 1534 2311 3226 5710 8010
3200 439 972 1641 2470 3453 6085 8581
3400 468 1034 1749 2629 3679 6460 9152
3600 497 1096 1857 2787 3906 6853 9724
3800 525 1158 1964 2946 4132 7210 10,295
4000 554 1220 2072 3104 4359 7586 10,866
4200 583 1282 2180 3263 4585 7961 11,437
4400 611 1344 2288 3422 4812 8336 12,008
4600 640 1406 2395 3580 5038 8711 12,579
4800 669 1468 2503 3739 5265 9087 13,151
5000 697 1530 2611 3897 5491 9462 13,722
5200 726 1592 2718 4056 5718 9837 14,293
5400 754 1654 2826 4215 5944 10,212 14,864
5600 783 1716 2934 4373 6171 10,588 15,435
5800 811 1778 3041 4532 6397 10,963 16,007
6000 840 1840 3149 4690 6624 11,338 16,578
6200 868 1902 3257 4849 6850 11,713 17,149
6400 897 1964 3364 5008 7077 12,089 17,720
6600 925 2026 3472 5166 7303 12,464 18,291
6800 954 2088 3580 5325 7530 12,839 18,863
7000 982 2150 3688 5483 7756 13,214 19,434
7200 1011 2212 3795 5642 7983 13,589 20,005
7400 1039 2274 3903 5801 8209 13,965 20,576
7600 1068 2336 4011 5959 8436 14,340 21,147
7800 1096 2398 4118 6118 8662 14,715 21,719
8000 1125 2460 4226 6276 8889 15,090 22,290
8200 1153 2522 4334 6435 9115 15,466 22,861
8400 1181 2584 4441 6594 9342 15,841 23,432
8600 1210 2646 4549 6752 9568 16,216 24,003
8800 1238 2708 4657 6911 9795 16,591 24,575
9000 1266 2770 4764 7069 10,021 16,967 25,146
9200 1295 2832 4872 7228 10,248 17,342 25,717
9400 1323 2894 4980 7387 10,474 17,717 26,288
9600 1351 2956 5087 7545 10,701 18,092 26,859
9800 1380 3018 5195 7704 10,927 18,467 27,431
10,000 1408 3080 5303 7862 11,154 18,843 28,002
Torque values are rounded to the nearest whole unit.
