12
pressure SQD-25-I SQD-50-I SQD-75-I SQD-100-I SQD-160-I SQD-270-I
bar Nm Nm Nm Nm Nm Nm
40 120 228 391 505 800 1310
60 180 342 580 760 1200 1965
80 232 470 769 990 1590 2675
100 290 587 957 1240 1985 3345
120 348 704 1146 1490 2380 4010
140 410 822 1335
1)
1735 2800 4705
160 469 934 1523 2005 3200 5375
180 531 1050 1712
1)
2255 3610 6050
200 590 1167 1901 2505 4010 6725
220 649 1284
1)
2089 2755
1)
4410 7395
240 705 1400 2278 3030 4870 8025
260 764
1)
1506 2467 3280 5275 8695
280 821 1622 2655 3520
1)
5610 9400
300 880 1738
1)
2844 3770 6010 10075
320 939 1854 3033 4020 6410 10745
340 1010 1970 3221 4270 6825
1)
11425
360 1070 2066 3410 4520 7225 12100
1)
380 1111 2180 3599
1)
4775 7625 12775
400 1170 2295 3787 5025
1)
8035 13450
420 1228 2410 3976 5275 8435
1)
14120
440 1286
1)
2525 4165 5525 8830 14800
460 1344 2643 4353 5775 9235 15475
480 1406 2758
1)
4542 6030 9635 16150
500 1465 2873 4731 6280 10035 16825
520 1524 2988 4919
1)
6530 10435 17495
540 1581 3103 5108 6795 10835 18175
1)
560 1639 3335 5297 7050
1)
11240 18850
580 1692 3454
1)
5486 7275 11640 19525
600 1750 3573 5674 7525 12045
1)
20200
620 1808
1)
3692 5863 7775 12445 20875
640 1876 3811 6052 8020 12845 21550
660 1934 3957 6240 8270 13245 22225
680 1986 4077 6429 8540
1)
13645 22900
700 2045 4197 6618 8790 14045 23575
720 2103 4317 6806 9040 14450 24250
740 2161 4437 6995
1)
9240 14850 24925
1)
760 2219 4570 7184 9490 15250 25600
780 2291 4690 7372 9730 15650 26275
800 2350
1)
4810
1)
7558
1)
9980
1)
16050
1)
26950
1)
TABLE METRIC - PRESSURE VERSUS TORQUE
B
NOTE:
1)
refer to table for maximum torque when using Allen-key drives.
