pressure SQD-25-I SQD-50-I SQD-75-I SQD-100-I SQD-160-I SQD-270-I
psi Ft.lbs Ft.lbs Ft.lbs Ft.lbs Ft.lbs Ft.lbs
600 92 174 298 385 610 999
800 122 232 399 515 814 1332
1000 153 290 497 644 1010 1665
1200 177 359 585 756 1213 2040
1400 206 418 683 883 1413 2381
1600 236 478 781 1009 1615 2722
1800 265 537 878 1137 1815 3059
2000 298 597 970
1)
1260 2034 3418
2200 328 657 1067 1386 2238 3760
2400 358 712
1)
1164 1529 2441 4100
2600 390
1)
771 1257 1656 2652 4444
2800 420 831 1354
1)
1783 2855 4788
3000 450 890 1451 1911 3059 5130
3200 480 950 1547 2038
1)
3262 5470
3400 508 1009 1642 2183 3508 5781
3600 538 1068 1738 2311 3715 6121
3800 568 1119 1835 2438 3920 6462
4000 596 1178 1931 2557 4075 6829
4200 626 1237 2025
1)
2685 4279 7170
4400 656 1296
1)
2121 2812 4483 7514
4600 686 1355 2218 2939 4686 7855
4800 716
1)
1414 2312 3066
1)
4900 8196
5000 755 1473 2409 3193 5104 8544
5200 786 1518 2505 3320 5307 8888
5400 816 1576 2601
1)
3448 5510 9230
5600 833 1634 2696 3578 5714 9574
5800 863 1692 2792 3705 5925 9918
6000 892 1751 2888 3832 6128
1)
10258
1)
this table is continued on the next page.
TABLE IMPERIAL - PRESSURE VERSUS TORQUE
C
NOTE:
1)
refer to table for maximum torque when using Allen-key drives.
A2
CONVERSION TABLE
Pressure:
1 bar = 14,514 psi
1 psi = 0,0689 bar
Torque:
1 Nm = 0,73756 Ft.lbs
1 Ft.lbs = 1,355818 Nm
