Enerpac W2000X - Page 28

28
6.2.2 Metric System Table - W15000X Series Cassettes
(see Fig.
20 for locations of dimensions S, H and G)
Drive Unit Cassette (S) Hex size (H) (G) Weight
Model
mm mm mm kg
W15000X W15209X 65 59.0 88.6 13.6
W15212X 70 59.0 88.6 13.6
W15215X 75 62.0 90.5 13.7
W15302X 80 64.5 92.9 14.2
W15085MX 85 69.5 96.6 14.9
W15090MX 90 75.0 101.8 15.6
W15312X 95 75.0 101.8 15.2
W15315X 100 80.5 103.1 14.8
W15402X 105 80.5 103.1 15.5
W15405X 110 87.5 114.8 15.6
W15115MX 115 87.5 114.8 16.1
6.2.3 Imperial System Table - W2000X Series Cassettes
(see Fig.
20 for locations of dimensions S, H and G)
Drive Unit Cassette (S) Hex size (H) (G) Weight
Model inch inch inch lbs
W2000X
W2101X 1
1
/16 1.22 2.11 4.19
W2102X 1
1
/8 1.22 2.11 4.19
W2103X 1
3
/16 1.22 2.11 4.19
W2104X 1
1
/4 1.22 2.11 4.19
W2105X 1
5
/16 1.22 2.11 4.48
W2106X 1
3
/8 1.22 2.11 4.43
W2107X 1
7
/16 1.22 2.11 4.37
W2108X 1
7
/16 1.32 2.29 4.51
W2109X 1
9
/16 1.32 2.29 4.44
W2110X 1
5
/8 1.32 2.29 4.38
W2111X 1
11
/16 1.44 2.38 4.63
W2112X 1
3
/4 1.44 2.38 4.57
W2113X 1
13
/16 1.44 2.38 4.46
W2114X 1
7
/8 1.54 2.48 4.69
W2115X 1 1
5
/16 1.54 2.48 4.64
W2200X 2 1.54 2.48 4.54
W2201X 2
1
/16 1.65 2.70 4.83
W2202X 2
1
/8 1.65 2.70 4.74
W2203X 2
3
/16 1.65 2.70 4.64
W2204X 2
1
/4 1.75 2.55 4.94
W2205X 2
5
/16 1.75 2.55 4.84
W2206X 2
3
/8 1.75 2.55 4.72
