Enerpac W2000X - Page 29

29
6.2.4 Imperial System Table - W4000X Series Cassettes
(see Fig.
20 for locations of dimensions S, H and G)
Drive Unit Cassette (S) Hex size (H) (G) Weight
Model inch inch inch lbs
W4000X
W4105X 1
5
/16 1.46 2.40 8.15
W4106X 1
3
/8 1.46 2.40 8.15
W4107X 1
7
/16 1.46 2.40 8.15
W4108X 1
1
/2 1.46 2.40 8.31
W4109X 1
9
/16 1.46 2.40 8.22
W4110X 1
5
/8 1.46 2.40 8.15
W4111X 1
11
/16 1.56 2.52 8.43
W4112X 1
3
/4 1.56 2.52 8.35
W4113X 1
13
/16 1.56 2.52 8.25
W4114X 1
7
/8 1.63 2.63 8.45
W4115X 1
15
/16 1.63 2.63 8.39
W4200X 2 1.63 2.63 8.28
W4201X 2
1
/16 1.73 2.89 8.65
W4202X 2
1
/8 1.73 2.89 8.53
W4203X 2
3
/16 1.73 2.89 8.42
W4204X 2
1
/4 1.83 2.78 8.73
W4205X 2
5
/16 1.83 2.78 8.61
W4206X 2
3
/8 1.83 2.78 8.47
W4207X 2
7
/16 1.95 3.00 8,96
W4208X 2
1
/2 1.95 3.00 8.86
W4209X 2
9
/16 1.95 3.00 8.67
W4210X 2
9
/16 2.07 3.08 9.14
W4211X 2
11
/16 2.07 3.08 9.03
W4212X 2
3
/4 2.07 3.08 8.84
W4213X 2
13
/16 2.18 3.21 9.32
W4214X 2
7
/8 2.18 3.21 9.17
W4215X 2
15
/16 2.18 3.21 8.96
W4300X 3 2.30 3.29 9.51
W4301X 3
1
/16 2.30 3.29 9.42
W4302X 3
1
/8 2.30 3.29 9.16
W4303X 3
3
/16 2.44 3.37 9.92
W4304X 3
1
/4 2.44 3.37 9.92
W4305X 3
5
/16 2.44 3.37 9.92
W4306X 3
3
/8 2.44 3.37 9.92
ENGLISH
