Enerpac W2000X - Page 31

31
6.2.6 Imperial System Table - W15000X Series Cassettes
(see Fig.
20 for locations of dimensions S, H and G)
Drive Unit Cassette (S) Hex size (H) (G) Weight
Model inch inch inch lbs
W15000X
W15207X 2
7
/16 2.32 3.49 30.72
W15208X 2
1
/2 2.32 3.49 30.72
W15209X 2
9
/16 2.32 3.49 30.72
W15210X 2
5
/8 2.32 3.49 30.72
W15211X 2
11
/16 2.32 3.49 30.72
W15212X 2
3
/4 2.32 3.49 30.72
W15213X 2
13
/16 2.44 3.56 30.62
W15214X 2
7
/8 2.44 3.56 30.39
W15215X 2
15
/16 2.44 3.56 30.08
W15300X 3 2.54 3.66 30.86
W15301X 3
1
/16 2.54 3.66 30.71
W15302X 3
1
/8 2.54 3.66 30.34
W15303X 3
3
/16 2.74 3.80 32.38
W15304X 3
3
/16 2.74 3.80 32.07
W15305X 3
5
/16 2.74 3.80 31.85
W15306X 3
3
/8 2.74 3.80 31.63
W15307IX 3
7
/16 2.74 3.80 31.32
W15308X 3
1
/2 2.74 3.80 30.98
W15309X 3
3
/16 2.95 4.01 31.70
W15310X 3
5
/8 2.95 4.01 31.70
W15311X 3
11
/16 2.95 4.01 31.70
W15312X 3
3
/4 2.95 4.01 31.70
W15313X 3
13
/16 2.95 4.01 31.70
W15314X 3
7
/8 2.95 4.01 31.70
W15315X 3
15
/16 3.17 4.06 34.02
W15400X 4 3.17 4.06 33.70
W15401IX 4
1
/16 3.17 4.06 33.41
W15402X 4
1
/8 3.17 4.06 33.09
W15403IX 4
3
/16 3.17 4.06 32.81
W15404X 4
1
/4 3.17 4.06 32.39
W15405X 4
5
/16 3.44 4.52 35.61
W15406X 4
3
/8 3.44 4.52 35.32
W15407X 4
7
/16 3.44 4.52 34.99
W15408IX 4
1
/2 3.44 4.52 34.63
W15409IX 4
9
/16 3.44 4.52 34.28
W15410IX 4
5
/8 3.44 4.52 33.72
ENGLISH
