6.3 Torque Settings
6.3.1 Metric System Torque Factor Calculation
To set the torque, adjust the pump pressure according to the following calculation:
Pump pressure (bar) = Torque (Nm) / Torque factor
W2000X W4000X W8000X W15000X
Torque factor
Metric system:
4.0085 8.2037 16.6432 30.1227
6.3.2 Metric System Pressure/Torque Table
W2000X W4000X W8000X W15000X
Pump Pressure (bar) Torque (Nm) Torque (Nm) Torque (Nm) Torque (Nm)
60 241 492 999 1,807
90 361 738 1,498 2,711
120 481 984 1,997 3,615
150 601 1,231 2,496 4,518
180 722 1,477 2,996 5,422
210 842 1,723 3,495 6,326
240 962 1,969 3,994 7,229
270 1,082 2,215 4,494 8,133
300 1,203 2,461 4,993 9,037
330 1,323 2,707 5,492 9,941
360 1,443 2,953 5,992 10,844
390 1,563 3,199 6,491 11,748
420 1,684 3,446 6,990 12,652
450 1,804 3,692 7,489 13,555
480 1,924 3,938 7,989 14,459
510 2,044 4,184 8,488 15,363
540 2,165 4,430 8,987 16,266
570 2,285 4,676 9,487 17,170
600 2,405 4,922 9,986 18,074
630 2,525 5,168 10,485 18,977
660 2,646 5,414 10,984 19,881
690 2,766 5,661 11,484 20,785
NOTICE
Torque values are rounded to the nearest whole unit.
