33
6.3.3 Imperial System Torque Factor Calculation
To set the torque, adjust the pump pressure according to the following calculation:
Pump pressure (psi) = Torque (Ft.lbs) / Torque factor
W2000X W4000X W8000X W15000X
Torque factor
Imperial system:
0.204 0.4175 0.847 1.533
6.3.4 Imperial System Pressure/Torque Table
W2000X W4000X W8000X W15000X
Pump Pressure (psi) Torque (Ft.lbs) Torque (Ft.lbs) Torque (Ft.lbs) Torque (Ft.lbs)
1,000 204 418 847 1,533
1,500 306 626 1,271 2,300
2,000 408 835 1,694 3,066
2,500 510 1,044 2,118 3,833
3,000 612 1,253 2,541 4,599
3,500 714 1,461 2,965 5,366
4,000 816 1,670 3,388 6,132
4,500 918 1,879 3,812 6,899
5,000 1,020 2,088 4,235 7,665
5,500 1,122 2,296 4,659 8,432
6,000 1,224 2,505 5,082 9,198
6,500 1,326 2,714 5,506 9,965
7,000 1,428 2,923 5,929 10,731
7,500 1,530 3,131 6,353 11,498
8,000 1,632 3,340 6,776 12,264
8,500 1,734 3,549 7,200 13,031
9,000 1,836 3,758 7,623 13,797
9,500 1,938 3,966 8,047 14,564
10,000 2,040 4,175 8,470 15,330
NOTICE
Torque values are rounded to the nearest whole unit
ENGLISH
