POINTS LIST
Unit Mode
FAN : ON OCCUPIED MODE
: OFF
: ON UNOCCUPIED MODE
OCCUPIED MODE : ENABLED/DISABLED
COOLING : ENABLED/DISABLED
ECONOMIZER : ENABLED/DISABLED
HEATING : ENABLED/DISABLED
UNOCCUPIED MODE : ENABLED DISABLED
Scheduler
If Enabled For Time Clock
CLOCK OVERRIDE: ON/OFF
OVERRIDE TIMER: 1,2 OR 3 HRS
Unit Operation
UNIT MODE : NO MODE
: HEATING MODE
: ECONOMIZER MODE
: COOLING MODE
ENABLE UNIT : ON / OFF
UNIT STATUS : OCCUPIED
: OFF
: UNOCCUPIED
HEATING : ON / OFF %
: L/O HI AMBIENT
COOLING : ON /OFF %
: L/O LOW AMBIENT
ECONOMIZER : ON/OFF %
: L/O HI AMBIENT
Discharge Temperature
And Setpoints
DISCHARGE TEMP : F OR C
DISCHAGRE STPT : F OR C
ADJ DISCH STPT : WRITE F/C READ F/C
SECONDARY DT TEMP : F OR C
ADJ SEC DT TEMP : WRITE F/C READ F/C
Ambient and
Damper Information
AMBIENT SENSOR : F OR C
ECON MIN POSITION : %
ADJ ECON MIN POS : %
VFD FEEDBACK : %
VFD L/O COOLING : NO / YES
SAVE SETPOINTS : OFF / ON
Additional
Inputs Outputs
To Next Page
