5 Troubleshooting
Symbol
Number of
flashes
Name
Description
Action
7
Quick hitch lock
button timeout.
Quick hitch lock
button not actuated
within the time
frame.
Restart the
quick hitch lock’s
activation
sequence by
deactivating the
quick hitch lock
switch.
8
Internal fault.
Internal system
monitoring.
Replace unit.
Symbol
Frequency
Description
Action
Slow
Flashes 1 time per
second
(1 Hz)
Break Tilt
Break (X1:18)
Troubleshoot cabling.
Fast
Flashes 10 times per
second
(10 Hz)
Short circuit Tilt
Short circuit (X1:18)
Troubleshoot cabling.
Slow
Flashes 1 time per
second
(1 Hz)
Break Extra1
Break (X1:19)
Troubleshoot cabling.
Fast
Flashes 10 times per
second
(10 Hz)
Short circuit Extra1
Short circuit (X1:19)
Troubleshoot cabling.
Slow
Flashes 1 time per
second
(1 Hz)
Break Extra2
Break (X1:20)
Troubleshoot cabling.
Fast
Flashes 10 times per
second
(10 Hz)
Short circuit Extra2
Short circuit (X1:20)
Troubleshoot cabling.
Slow
Flashes 1 time per
second
(1 Hz)
Break, dump valve
Break (X1:21)
Troubleshoot cabling.
