Section 15 00-02-0831
2013-03-21 - 2 -
Set Point Adjustment for the DF757
1.
Locate the threaded adjustment shaft and adjustment knobs (see the
following drawings).
2.
To increase the low-level set point, rotate the lower knob
counterclockwise.
NOTE: If the adjustment shaft turns when rotating the adjustment knobs,
firmly grasp the adjustment shaft with a pair of needle nose pliers, and
then rotate the knob.
